LMP2014MT
www.ti.com
SNOSAK6B–DECEMBER2004–REVISEDMARCH2013
LMP2014MTQuadHighPrecision,Rail-to-RailOutputOperationalAmplifier
CheckforSamples:LMP2014MT
1
FEATURES
DESCRIPTION
TheLMP2014MTisamemberofTexasInstruments'
2
•(ForV
S
=5V,TypicalUnlessOtherwiseNoted)
newLMP
TM
precisionamplifierfamily.The
•LowSpecifiedV
OS
OverTemperature60µV
LMP2014MToffersunprecedentedaccuracyand
•LowNoisewithNo1/f35nV/√Hz
stabilitywhilealsobeingofferedatanaffordable
price.Thisdeviceutilizespatentedtechniquesto
•HighCMRR130dB
measureandcontinuallycorrecttheinputoffseterror
•HighPSRR120dB
voltage.Theresultisanamplifierwhichisultrastable
•HighA
VOL
130dB
overtimeandtemperature.IthasexcellentCMRR
andPSRRratings,anddoesnotexhibitthefamiliar
•WideGain-BandwidthProduct3MHz
1/fvoltageandcurrentnoiseincreasethatplagues
•HighSlewRate4V/µs
traditionalamplifiers.Thecombinationofthe
•LowSupplyCurrent3.7mA
LMP2014characteristicsmakesitagoodchoicefor
transduceramplifiers,highgainconfigurations,ADC
•Rail-to-RailOutput30mV
bufferamplifiers,DACI-Vconversion,andanyother
•NoExternalCapacitorsRequired
2.7V-5Vapplicationrequiringprecisionandlongterm
stability.
APPLICATIONS
OtherusefulbenefitsoftheLMP2014arerail-to-rail
•PrecisionInstrumentationAmplifiers
output,alowsupplycurrentof3.7mA,andwide
•ThermocoupleAmplifiers
gain-bandwidthproductof3MHz.Theseextremely
versatilefeaturesfoundintheLMP2014providehigh
•StrainGaugeBridgeAmplifier
performanceandeaseofuse.
ConnectionDiagram
Figure1.14-PinTSSOP–TopView
SeePackageNumberPW
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©2004–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
