VIN

EN

COMP

CSH

1

2

3

4

HSN

HSP

RPD

IS

16

15

14

13

RCT

AGND

OVP

nDIM

5

6

7

8

VCC

GATE

PGND

DDRV

12

11

10

9PWM

I

LED

V

IN

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

LM3421

,

LM3423

SNVS574G–JULY2008–REVISEDJULY2019

LM342xN-ChannelControllersforConstant-CurrentLEDDrivers

1

1Features

1

•V

IN

RangeFrom4.5Vto75V

•High-SideAdjustableCurrentSense

•2-Ω,1-APeakMOSFETGateDriver

•InputUndervoltageandOutputOvervoltage

Protection

•PWMandAnalogDimming

•Cycle-by-CycleCurrentLimit

•ProgrammableSwitchingFrequency

•ZeroCurrentShutdownandThermalShutdown

•LEDOutputStatusFlag(LM3423andLM3423-Q0

Only)

•FaultStatusFlagandTimer(LM3423and

LM3423-Q0Only)

2Applications

•LEDDrivers:Buck,Boost,Buck-Boost,and

SEPIC

•IndoorandOutdoorAreaSSL

•Automotive

•GeneralIllumination

•Constant-CurrentRegulators

3Description

TheLM3421andLM3423familyofdevicesare

versatilehighvoltageN-channelMOSFETcontrollers

forLEDdrivers.Theycanbeeasilyconfiguredin

buck,boost,buck-boostandSEPICtopologies.This

flexibility,alongwithaninputvoltageratingof75V,

makesthethesecontrollersidealforilluminating

LEDsinalargefamilyofapplications.

Adjustablehigh-sidecurrentsensevoltageallowsfor

tightregulationoftheLEDcurrentwiththehighest

efficiencypossible.TheLM3421andLM3423devices

usepredictiveoff-time(PRO)control,whichisa

combinationofpeakcurrent-modecontrolanda

predictiveoff-timer.Thismethodofcontroleasesthe

designofloopcompensationwhileprovidinginherent

inputvoltagefeed-forwardcompensation.

TheLM3421andLM3423devicesincludeahigh-

voltagestart-upregulatorthatoperatesoverawide

inputrangeof4.5Vto75V.TheinternalPWM

controllerisdesignedforadjustableswitching

frequenciesofupto2MHz,thusenablingcompact

solutions.

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

LM3421HTSSOP(16)5.00mm×4.40mm

LM3423HTSSOP(20)6.50mm×4.40mm

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

TypicalBoostApplication
