1. Drums
2. Hardware
Sound Focus Pad
a
c
b
Leg Bracket
d
e
f
h
Thank you for purchasing the TAMA Cocktail-JAM, or Cocktail-JAM drum kit. In order to ensure safe usage and to take full advantage of this product’s capabilities,
please read this manual before use. Keep the manual in a safe place for future ference.re
This produ contains DEHP or other phthalate chemicals known to thect
state of California to cause birth defects and other reproductive harm.
These instructions were issued on May, 2017.
Specifications and improvements subject to change without notice.
<2-1> Insert the connecting pipes into
the 3 mounting brackets (d) on the bass
drum, and tighten the T-nuts to fix them in
place. Then, fixing the floor tom according
to pipe’s memory locks, you can set up
the floor tom in standard height.
<2-2> To set up the floor tom, connect the 3
pipes fr
om the bass drum to the floor tom pipe
brackets (e). You can osition the floor tom p
at a standard height according to the pipe’s
memory locks, or position at your desired
height and then adjust the memory locks
accordingly.
*1 The it in this photo is the Cocktail-JAM drum k
kit. The Cocktail-JAM Mini only utilizes 2 pipe
brackets and connecting pipes, instead of 3.
<3-1> Set up the tom der to your hol
prefer
red playing position on one of the 3
connecting pipes. Attach the clamp (f) to
one of the pipes, and tighten the T-nut to
secure it.
<3-2> Attach the bracket of tom-tom
or the snare drum to the rod of the tom
holder (g), and tighten the T-nut to secure
it. The ball on the tom der (h) allows hol
you to adjust the position and angle of the
tom-tom or snare drum. Simply loosen
the T-nut, adjust to the desir
ed posi on ti
and angle, and then retighten to secure it
in place.
You can also attach cymbals or var us percus on instruments to the connecting io si
pipes. For a tighter and more isola d bass drum sound, place Sound Focus Pad on te
top of the bass drum.
Storage
Store all 4 drums in one bag. First, put the
cushion (i) around the i ide of the bass ns
drum, and nest the snare drum inside
of it. After storing them in the bag, put
Sound Focus Pad (j) on top of the two
drums. Then, put the cushion (k) around
the two drums. Then, put the cushion
(k) around the in de of the floor tom, si
and nest the tom-tom in de of it. Finally, si
put them on Sound Focus Pad (j), which
s
houl be on top of the bass drum and d
snare drum, and zip up the bag.
<1-1> Insert the bass drum legs into the 4
leg brackets (a) on the bass drum, and
tighten the T-bolts to fix them in place.
The 2 straight legs should be on the
drummer’s side. The 2 curves legs should
face away from the drummer.
<1-2> Attach the connecting bar for the
drum pedal to the 2 straight legs on the
player’s side. Insert the bass
drum legs
into the holes (b) on the plastic parts of
the connecting ar. From the player’s b
view, the plate of connecting bar should
be posi n behind the 2 legs.tio ed
<1-3> Attach the drum pedal to the
connecting bar. The pedal clamp should
be centered to the marked osi on (c) on p ti
the connecting bar, allowing the pedal
beater to hit the center of the bass drum
head. Also, adjust the length of bass drum
l
egs so that the pedal chain is not in
contact with the bass drum head.
Assembly
1. Bass Drum
2. Floor Tom
3. Tom Tom & Snare Drum
Tom Tom
Snare Drum
Floor Tom
Bass Drum
Drum Pedal
Connecting Bar for Drum Pedal
Tom Holder
Connecting
Pipes(*1)
Bass Drum Legs
(Audience Side)
Bass Drum Legs
(Player Side)
http://www.tama.com
Set-up Examples
j
k
i
“Co ailckt
-
JA stM” Drum Kit n I ruct Manualion
Store the hardware (drum pedal, bass drum legs, connecting
bar for drum pedal, connecting pipes, and tom h ders) in the ol
separate hardware bag It is easiest and most compact to .
pack the bass drum pedal first, and then add the rest of the
hardware.
g
Sie können ein PDF dieser Sicherheitsanweisung auf Deutsch unter http://www
点击此处查看 PDF 版的中文安全使用说明：
http://www.tama.com
Вы м етеож н тиай это руководство по технике безопасности в фор тема PDF на ру омсск языке по ад суре http://www.ta a.m com.
Pode encontrar um PDF deste Manual de Instruções de Segurança em português em http://www.tama.com.
Można znaleźć PDF niniejszej instrukcji bezpieczeństwa w języku polskim na http://www.tama.com.
Encontrará disponible este Manual de instrucciones de seguridad en formato PDF y en
español en http://www.tama.com.
È possibile trovare un PDF di questo Manuale di istruzioni per la sicurezza in italiano all’indirizzo http://www.tama.com.
V w.tama.com.ous pouvez trouver un PDF de ce manuel d'instructions de sécurité en français sur le site http://ww
