StarTech.com PR22GIP-NETWORK-CARD Handleiding
Pagina's 2 Engels Netwerkkaart/adapter
Bekijk de handleiding van StarTech.com PR22GIP-NETWORK-CARD gratis online of download de PDF. 43 mensen vonden deze handleiding nuttig. Vraag over dit model? Stel een vraag
Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: August 9, 2024
Product ID
PR22GIP-NETWORK-CARD
Port/LED/ConnectorFunction
1Bracket
• Secures the card to the Host Computer Case
• The comes pre-installedFull Prole Bracket
• The is included Low Prole Bracket
2
Ethernet Ports
• Connect an to the Ethernet CableNetwork Card
• Supports 2.5Gbps, 1Gbps, 100Mbps, and 10Mbps
• Supports and IEEE 802.3atIEEE 802.3af
• RightLED Indicator Link Speedis
• Solid Green: 2.5Gbps
• Solid Amber: 1Gbps
• O: 10/100Mbps
• LeftLED Indicator Link Statusis
• Solid Green: Active link
• Flashing Green: Activity
3
Power Over Ethernet
(PoE) LED Indicator
• Solid Green: PoE has been negotiated and power is
being supplied to the Powered Device
• O: No power output has been negotiated
2-Port PCIe 2.5GBase-T Ethernet PoE Network Adapter Card - Intel
4PCIe 2.0 p1-x2 Connector• Insert into a on the PCI Express SlotHost Computer
5
PCIe Power
Connector
• Connect 8-Pin PCIe PowerHost Computer’s from the
Power Supply
6LP4 Power Connector
• Connect from the LP4 PowerHost Computer’s
Power Supply
Package Contents
• Network Card x 1
• Low Prole Bracket x 1
• Quick-Start Guide x 1
Requirements
For the latest requirements, please visit: www.StarTech.com/PR22GIP-NETWORK-CARD
• Host Computer with an available PCI Express 2.0 or greater slot (x2, x4, x8, or x16)
Installation
Install the PCI Express Card
WARNING! Static Electricity PCI Express Cardscan severely damage. Ensure that
you are adequately before you open your or touch GroundedHost Computer Case
the . You should wear an oruseanPCI Express CardAnti-Static Strap Anti-Static
Mat Anti-Static Strap when installing any Host Computer component. If an isn’t
available, discharge any built-up static electricity by touching a large Grounded
Metal SurfacePCI Express Card for several seconds. Only handle the by its edges and
don’t touch the gold connectors.
1. Turn o the and any that are connected to it Host Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the back of the .Power Cable Host Computer
3. Disconnect any that are connected to the .Peripheral Devices Host Computer
4. Remove the from the . Cover Host Computer Case
Note: Consult the documentation that came with the for details Host Computer
about doing this safely.
5. Locate an open and remove the corresponding PCI Express SlotSlot Cover Plate
from the back of the . Host Computer Case
4
5
2
6
1
3
