For additional self-service support options and community forums, please visit: www.StarTech.com/support

Revision: May 7, 2025

Quick-Start Guide

Product ID

NOTECONS02-VGA-MDP

NOTECONS02

MDP2VGA2

ComponentFunction

1LED Indicators

• Server KB/Mouse:

• Solid: Emulated keyboard/mouse is functioning

• Blinking: Brief ashing indicates activity (i.e., mouse movement), and

constant ashing signals a USB connection issue

• Server VGA:

• Solid:Indicates a valid VGA signal is detected

• O: VGA Input disconnected or unsupported

Note: Only activates after initial software connection

• User Console Link/Activity:

• Solid: Laptop connection is detected

• Blinking: USB is disconnected, and blinks briey during video

transmission

2VGA Input

• Connect directly to a on a or VGA OutputComputerServer

• Connect to the on the VGA OutputMDP2VGA2

3Host Connection

• Use the included to connect the USB-A to USB Mini-B Cable

NOTECONS02Laptop to a

4USB Connection• Connect to a on a or USB-A PortComputerServer

5Mini DisplayPort Connector• Connect to a on a or Mini DisplayPort OutputComputerServer

6VGA Port • Connect to the on the VGA Input NOTECONS02

Package Contents

• NOTECONS02 x 1

• MDP2VGA2 x 1

• USB-A to USB Mini-B Cable x 1

• Quick-Start Guide x 1

KVM to USB Crash Cart Adapter with Mini DisplayPort to VGA Adapter

*Products may vary from image

2

1

5

4

3

6
