StarTech.com IES81GPOEW Handleiding

StarTech.com Schakelaar IES81GPOEW

Bekijk gratis de handleiding van StarTech.com IES81GPOEW (12 pagina’s), behorend tot de categorie Schakelaar. Deze gids werd als nuttig beoordeeld door 10 mensen en kreeg gemiddeld 4.9 sterren uit 5.5 reviews. Heb je een vraag over StarTech.com IES81GPOEW of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/12

Manual Revision: 01/17/2017

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/IES81GPOEW.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

IES81GPOEW

8-Port Gigabit Ethernet Switch

(4-Port PoE+) - Managed

*actual product may vary from photos

Quick-start guide

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (A)/NMB-3(A)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Quick-start guide

Table of Contents

Introduction ............................................................................................1

Product diagram 1 ........................................................................................................................................

Package contents 2 ......................................................................................................................................

Requirements 3 .............................................................................................................................................

About the LED indicators ......................................................................3

Wire the power inputs ...........................................................................4

Reboot the network switch ..................................................................4

Reset to the default factory settings ..................................................4

Installation ..............................................................................................5

Install the network switch onto a wall 5 ...............................................................................................

Install the switch onto a magnetic surface 6 ......................................................................................

Mount the switch onto a DIN rail 7 ........................................................................................................

Technical support ...................................................................................8

Warranty information ............................................................................8

Product specificaties

Merk:	StarTech.com
Categorie:	Schakelaar
Model:	IES81GPOEW
Kleur van het product:	Zwart
Gewicht:	650 g
Breedte:	148 mm
Diepte:	134 mm
Hoogte:	25 mm
Type stekker:	Type M
Gewicht verpakking:	930 g
Breedte verpakking:	173 mm
Diepte verpakking:	30 mm
Hoogte verpakking:	92 mm
Materiaal behuizing:	Staal
Internationale veiligheidscode (IP):	IP30
LED-indicatoren:	Activity, Link, Power
Stroom:	1 A
Snelstartgids:	Ja
Certificering:	CE, FCC, RoHS
Ingangsspanning:	12 - 48 V
Netwerkstandaard:	IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3z
Temperatuur bij opslag:	-40 - 90 °C
Rack-montage:	Nee
Mean time between failures (MTBF):	100000 uur
Ophangsysteem voor aan de muur:	Ja
Maximale overdrachtssnelheid van gegevens:	2000 Mbit/s
Auto MDI/MDI-X:	Ja
Virtuele LAN-functies:	Tagged VLAN
Access Control List (ACL):	Ja
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	- Gbit/s
MAC-adrestabel:	- entries
10G support:	Nee
Datastroombeheer:	Ja
Switch type:	Managed
Aantal basis-switching RJ-45 Ethernet-poorten:	8
Netstekker:	DC-in ingang
Switch-laag:	L2
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Jumbo Frames ondersteuning:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
(Buitenste) hoofdverpakking hoogte:	475 mm
(Buitenste) hoofdverpakking breedte:	335 mm
(Buitenste) hoofdverpakking lengte:	363 mm
Hoeveelheid per (buitenste) hoofdverpakking:	10 stuk(s)
Buffergrootte:	512 KB
Bedrijfstemperatuur (T-T):	-40 - 75 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Totaal Power over Ethernet (PoE)-budget:	120 W
Aantal Power over Ethernet plus (PoE +)-poorten:	4
Jumbo frames:	9000
Store-and-forward:	Ja
Klemmenblok inclusief:	Ja
Vermogen per poort Power over Ethernet (PoE):	30 W
Klemmenblokpoort:	Ja
