For additional self-service support options and community forums, please visit: www.StarTech.com/support
Revision: June 3, 2025
Quick-Start Guide
Product ID
4K7012IC-EXTEND-HDMI
4K7014IC-EXTEND-HDMI
Transmitter
Receiver
FeatureFunction
1
Reset Button
• Transmitter and Receiver: Reboots the unit which will cause
a renegotiation of connected devices
2
Power Indicator
• Solid Blue: Unit is receiving Power
Receiver Only:
• Flashing Blue: Receiver is pairing with the Transmitter
3
On/O Switch• Turn On or O the Transmitter
4
DC Power Input
• Power the Transmitter or Receiver using the included Power
Adapter
5
IR Output• Connect the IR Blaster to the Transmitter
6
HDMI Input• Connect to an HDMI Source Device
7
HDMI Output• Connect to an HDMI Display
8
RJ45 Port
• Connect the Transmitter and Receiver together, using a
CAT6/6a Ethernet Cable (sold separately)
9
Receiver Power Input
• Port not in use
• HDMI Receiver receives power over the Cat6/Cat6a Cable
from the HDMI Transmitter
10
IR Input• Connect the IR Receiver to the Receiver
11
Grounding Nut
(Not Shown)
• Receivers only
• Connect a Grounding Wire from the Grounding Nut to a
Grounded Outlet or other veried Grounding Point
HDMI Splitter and Extender - 4K 60Hz - 230ft (70m)
1
*Product may vary from image
4K7012IC-EXTEND-HDMI shown
23
456788
1
8
2
97
10
