VS-232007

VS-233010

VS-233011

VS-233014

Apply Teflon Tape in a clockwise direction to all

threaded connections.

1

2

3

4

5

6

NOTE: Inspect Diverter to be sure Sealing

Washer is in place within Coupling Nut.

Thread Coupling Nut of Diverter onto Shower

Arm. Tighten with Adjustable Wrench.

Thread Fixed Showerhead onto front outlet of

Diverter. Tighten with Adjustable Wrench.

Thread Hose end marked “HAND SHOWER”

onto base of Handheld Shower. Hand tighten

connection.

Adjustable

Wrench

Teflon

Tape

Keep your Speakman product looking new by

cleaning it periodically with a soft cloth. Avoid

abrasive cleaners, steel wool, and harsh chemicals

as these will dull the finish and void your warranty.

Cover your drain to prevent loss of parts.

Be sure to read instructions thoroughly before

beginning installation. Do not overtighten any

connections or damage may occur.

Thread Hose end marked “VACUUM BREAKER”

onto bottom outlet of Diverter. Hand tighten

connection.

92-VS-23XXXX-R1

NOTE: Fixed

Showerhead

may differ

from shown.

Place Hand Shower into Diverter Assembly.

Phillips

Screwdriver

Helpful:

NOTE:

Showerheads

may differ

from shown.

NOTE: Fixed

Showerhead

may differ

from shown.
