SPEAKMAN COMPANY
S-3014 Installation, Operation & Maintenance Instructions
ANYSTREAM
®
SHOWERHEAD
DESCRIPTION
Polished chrome plated ANYSTREAM
®
S-3014 Showerhead with a 3-3/4” outer spray adjustment ring. 5 self-
cleaning plunger nozzles resist scale build-up and provide 45 spray streams for a full body coverage pattern. The
center core nozzle delivers twelve massaging jets and a combination spray is included. Water conserving pressure
compensating AUTOFLO® device reduces flow to 2.5 GPM/9.46LPM maximum, to meet existing ANSI A112.18.1
Standard. ½” NPT inlet.
OPTIONS
SPECIFICATIONS
◊BN –Brushed Nickel
◊S-3014-E2 – Low Flow Showerhead
(2.0 GPM/ 7.6 LPM)
◊S-3014-BN-E2 – Low Flow Brushed
Nickel Showerhead
(2.0 GPM/ 7.6 LPM)
SUPPLY INLET: ½” NPT
FLOW RATE: 2.5 GPM/9.46LPM MAXIMUM
SHIPPING WEIGHT: 1.0 LBS.
INSTALLATION
Remove the old shower head from the shower arm. Clean of the shower arm. Wrap o any debris on the threads
Teflon tape around the shower arm threads in a clockwise direction. Turning in a clockwise direction, screw the
new Speakman shower head onto the shower arm. Tighten with a wrench. Turn the water supply on and check for
leaks.
OPERATION
To adjust the spray pattern of the shower head, simply rotate the outer ring to the desired spray (Full-Body, Dual
action or Massage). The outer ring can rotate 360°.
MAINTENANCE
1/11
92-3200
Rev. 1
The gleaming finish of your SPEAKMAN ANYSTREAM
®
shower head can be cleaned by using mild soap and warm
water. Dry immediately with a soft, clean cloth for best results. The flow control device limits water flow to 2.5 gallons
per minute. The small orifices may become clogged with scale and other minerals found in potable water. To clean the
flow regulator, simply remove the shower head from the bent arm, dislodge the flow regulator which is located in the
inlet and clean as necessary.
ROUGH-IN MEASUREMENTS
Product improvements may cause
specification and dimensional
changes without notice.
SPEAKMAN
SPEAKMAN
SPEAKMAN
SPEAKMANSPEAKMAN
®
PO Box 191 Wilmington, DE 19899 Phone: 800-537-2107 Fax: 800-977-2747
Visit us on the web at www.speakmancompany.com
