Pagina 1/1
System Type
10” Multi-Purpose, High-Performance,
Weatherized 2-Way Passive Loudspeaker
Impedance (Nominal)
1
8 ohm
Sensitivity dB @ 2.83 V / 1 M
93 dB
Sensitivity dB @ 1 W / 1 M
2
93 dB
Frequency Response ( ±3 dB)
3
73 Hz - 20 kHz
Frequency Response ( ±10 dB)
3
50 Hz
Max. Program Power
4
600 W
Max. Continuous Power RMS
5
300 W
Tap Selector
n/a
Transducer: Low-Frequency Driver
10” High-Efficiency Weather Treated Woofer
Transducer: High-Frequency Driver
1” Titanium Compression Driver with 90 x 90
Horn Flare
Low-Frequency Voice Coil
2 in. / 50.8 mm
Crossover Frequency
2 kHz
Network Type: Low Pass
12 dB per octave, 2nd order
Network Type: High Pass
12 dB per octave, 2nd order
Enclosure Material
Reinforced Radiata Pine with Weatherized
Urethane Bed-Liner Coating
Grille
Weather-Treated Electro-Plated & Powder-Coated
Steel Grille (passed MIL-STD-810G test,
Method 509)
Inputs
4-pin, 5.08 mm Euroblock for individual or daisy
chain connection
Colors
Black, White
Length
13.75 in / 349.3 mm
Width
12.6 in / 320.0 mm
Height
19.5 in / 495.3 mm
Weight
40 lbs / 18.1 kg
Packaging
One per box
Included Accessories
Weather-Proof Terminal Cover Plate,
Water-Tight Cable Glands
Optional Accessories
Pan & Tilt Surface-Mount Bracket, Fly Mount Kit
IP Rating
IP55
Certications
CE, RoHS, MIL-STD-810G
TAA Compliant (Trade America)
Yes
BAA Compliant (Made in USA)
Yes
1
Impedance listed per IEC 60268-5 with a minimum less than
80% the nominal impedance
2
1 W/1 M sensitivity determined using nominal impedance
3
Frequency response measured in half or full space as dictated
by speaker mounting conguration
4
Max program power is 3 dB above max continuous power
5
Continuous power rating, EIA-426-B test
6
Max output based on max continuous power
PS1090i PRODUCT SPECIFICATIONS
10” Multi-Purpose, High-Performance,
Weatherized 2-Way Passive Loudspeaker
PS1090i
rev. 6.7.24
PRELIMINARY
INFORMATION
Description
The PS1090i is a high-output, passive 8 ohm speaker with a
high-efciency, weather-treated 10-inch woofer and an advanced
compression driver with a 90x90° horn are to deliver pristine highs
and robust bass. With 300 W continuous (600 W peak) of power
handling and 93 dB sensitivity, the PS1090i speaker is equipped for
the most demanding live or installed audio applications. The PS1090i
and PS1290i models are further enhanced by an outdoor IP55
rating, making them suitable for both indoor and outdoor use.
Designed for foreground and background applications in nightclubs,
live venues, houses of worship or any space that requires powerful
installed or portable sound, these speakers blend high performance
with exceptional versatility.
Features
• One 10” weather-treated, high-efciency woofer
• One 1” compression driver with 90x90° horn are
• Weather-Treated Electro-Plated & Powder-Coated Steel Grille
(passed MIL-STD-810G test, Method 509)
• Reinforced radiata pine enclosure
• Durable urethane bed-liner coating, available in
Black or White
• Optional Accessories: Pan & Tilt Surface-Mount
Bracket, Fly Mount Kit
• TAA & BAA Compliant -- Proudly made in the USA
