Pagina 1/34
5-014-053-11 (2)
Recording Option
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
HKCU-REC55
© 2019 Sony Corporation
2
Table of Contents
Overview .............................................................. 3
System Configuration........................................... 4
Name and Function of Parts ................................. 6
Front Panel...................................................................... 6
Rear Panel....................................................................... 7
Preparation and Configuration............................. 8
Configuring Using the CCU............................................. 8
Configuring Using the Web Menu ................................. 8
Accessing the Web Menu .............................................. 8
Network Settings ............................................................ 8
Web Browsers................................................................. 8
Initial Access ................................................................... 8
Logging In and Logging Out .......................................... 9
Input/Output Settings.................................................... 9
Timecode Settings.......................................................... 9
Audio Settings ...............................................................10
Video Settings ...............................................................10
Character Superimposition Settings .............................10
Storage................................................................ 11
Internal Storage............................................................. 11
USB Drives...................................................................... 11
NAS ................................................................................ 12
Recording, Playback, and File Operations ...........12
Recording ...................................................................... 12
Playback......................................................................... 12
File Operations .............................................................. 13
File Transfer ................................................................... 13
CCU Menu........................................................... 14
Web Menu ...........................................................15
Web Menu Organization ...............................................15
Home Screen .................................................................16
Status Screen .................................................................18
System Screen ...............................................................19
Port Screen ................................................................... 24
File Screen......................................................................27
Storage Screen ............................................................. 28
Usage Precautions...............................................31
Troubleshooting................................................. 32
Error Messages ............................................................. 32
Warning Messages ....................................................... 33
Specifications ..................................................... 34
3
Overview
The HKCU-REC55 Recording Option is designed to be
installed in an HDCU5500/3500 Camera Control Unit and
enables recording of signals from a camera connected to
the camera control unit (CCU).
It is equipped with internal storage memory, which
supports recording and playback, and supports file transfer
to external storage, such as a USB drive or NAS. It supports
the ISO REC function
1)
by transferring files to external
storage while recording to internal storage.
HD signal recording, playback, and file transfer are
supported by attaching the HKCU-REC55 to an HDCU3500.
4K (QFHD) signal and HD signal simultaneous recording,
playback, and file transfer are supported by installing
HZCU-UHD35 4K/HDR Processor Software and an
HZCU-UHDR50 4K Recording License on an HDCU3500.
4K (QFHD) signal and HD signal simultaneous recording,
playback, and file transfer are supported by installing an
HZCU-UHDR50 4K Recording License on an HDCU5500.
The unit is controlled using PWA-RCT1 Record Control
Software.
1) ISO REC (ISOlation RECording): Function to record to external
storage separately from the internal storage of the unit for
backup or other purposes.
