Pagina 1/2

電源電圧 DC12V(カメラまたはオプチカルマルチプレックスユニット
より供給)
消費電力 最大3.7W
動作温度 0℃〜40℃
動作湿度 20%〜80%(結露しないこと)
保存温度 −20℃〜+60℃
保存湿度 20%〜95%(結露しないこと)
外形寸法 134×25.6×74.6mm(幅/高さ/奥行き)(突起部含まず)
質量 約125g
付属品 取扱説明書(1)
本機の仕様及び外観は、改良のため予告なく変更することがありますが、ご
了承ください。
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用する
と電波妨害を引き起こすことがあります。この場合には使用者が適切な対
策を講ずるよう要求されることがあります。
VCCI-A
4-195-082- (1)01
Analog SD Output
Card
取扱説明書
お買い上げいただきありがとうございます。
ご使用にあたっては、
HD
カラービデオカメラ
BRC-Z330
の取扱説明書の
「安全のために」と「 」、「 」をよくお読みください。お読み
になったあとは、いつでも見られるところに必ず保管してください。
Operating Instructions
Mode d’emploi
Manual de instrucciones
アナログ
SD
出力カード
BRBK-SA1
2010 Sony Corporation Printed in Japan
この表示の注意事項を守らないと、感電や
その他の事故によりけがをしたり周辺の物
品に損害を与えたりすることがあります。
警告表示の意味
この取扱説明書および製品では、次
のような表示をしています。表示の
内容をよく理解してから本文をお読
みください。
行為を指示する記号
安全のために
ソニー製品は安全に充分に配慮して設計されています。しかし、まちがっ
た使いかたをすると、火災や感電などにより死亡や大けがなど人身事故に
つながることがあり、危険です。
事故を防ぐために次のことを必ずお守りください。
•安全のための注意事項を守る。
•破損したら使わずに、お買い上げ店またはソニーのサービス窓口に修理
を依頼する。
注意を促す記号
下記の注意を守らないと、
けがをしたり、周辺の物品に を与えることがあります。損害
基板を取り付けの際は電源プラグを抜く
この取扱説明書で説明している基板をカメラやオプチカルマルチプレックスユ
ニットのスロットに取り付けるときは、電源プラグを抜いてください。さもな
いと感電や故障の原因となることがあります。
基板の取り付けは注意深く
この取扱説明書で説明している基板をカメラやオプチカルマルチプレックスユ
ニットのスロットに取り付けるときは、部品や基板などの角で、手や指にけが
をしないように注意深く作業してください。保護手袋をして作業することをお
すすめします。
コネクターはきちんと接続する
•コネクター(接続端子)の内部に金属片を入れないでください。ピンとピンが
ショート(短絡)して、火災や故障の原因となることがあります。
•コネクターはまっすぐに差し込んで接続してください。斜めに差し込むと、
ピンとピンがショートして、火災や事故の原因となることがあります。
•コネクターに固定用のスプリングやネジがある場合は、それを用いて確実に
固定してください。接続不良を防ぎます。
•アース線のあるコネクターには必ずアースを接続してください。
適正な環境で使う
取扱説明書に記されている使用環境(使用温度・湿度など)でお使いください。使
用条件以外でのご使用は、火災や感電の原因となることがあります。
日本語
本機は、ソニーのHDカラービデオカメラBRC-Z330または HDオプチカルマ
ルチプレックスユニットBRU-SF10 専用のインターフェースカードです。
本機を使用すると、ビデオカメラで撮影した映像をコンポジットビデオ信号や
Sビデオ信号、RGB信号、コンポーネントビデオ信号に変換して出力すること
ができます。出力信号の切り換えは、カメラ側のメニューで行います。
本機の取り付けかたおよび取り付け後の操作方法については、カメラまたは
オプチカルマルチプレックスユニットの取扱説明書をご覧ください。
主な仕様
出力端子 VIDEO:BNC 型(1)
SVIDEO:4ピンミニDIN(1)
RGB/SYNC:D-sub9ピン(1)
出力信号 コンポジットビデオ:1Vp-p、75Ω不平衡、同期負
Sビデオ:Y:1Vp-p、75Ω不平衡、同期負
C:コンポジットビデオのクロマと同レベル
R/G/B:1Vp-p、75 Ω不平衡(同期ON時)
コンポーネントビデオ:Y:1Vp-p、75 Ω不平衡、同期負
Cr/Cb:0.7Vp-p
SYNC:2Vp-p、75Ω不平衡、同期負
RGB/SYNC
端子のピン配列(
D-sub 9
ピン)
ピン番号 機能
1 GND
2 GND
3 R/Cr
4 G/Y
5 B/Cb
6 /Yコンポジットビデオ
7 SYNC
8 GND
9 – /C
English
The BRBK-SA1 interface card is designed to be used exclusively
with the Sony BRC-Z330 HD Color Video Camera or the Sony
BRU-SF10 HD Optical Multiplex Unit.
The BRBK-SA1 converts the image shot by the camera into the
composite video signal, S video signal, RGB signal or component
video signal to be output. The output signal can be selected with the
menu of the camera.
For installation of the interface card and the operations after it is
installed, refer to the Operating Instructions supplied with the camera
or the Optical Multiplex Unit.
For the customers in the U.S.A.
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority to
operate this equipment.
All interface cables used to connect peripherals must be
shielded in order to comply with the limits for a digital device
pursuant to Subpart B of Part 15 of FCC Rules.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
For customers in Canada
This Class A digital apparatus complies with Canadian
ICES-003.
For the customers in Europe, Australia and New
Zealand
WARNING
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the user
may be required to take adequate measures.
In the case that interference should occur, consult your nearest
authorized Sony service facility.
For the customers in Europe
The manufacturer of this product is Sony Corporation, 1-7-1
Konan, Minato-ku, Tokyo, Japan.
The Authorized Representative for EMC and product safety is
Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Germany.
This apparatus shall not be used in the residential area.
Specifications
Output connector VIDEO: BNC type (1)
S VIDEO: Mini DIN 4-pin (1)
RGB/SYNC: D-sub 9-pin (1)
Output signal Composite video: 1 Vp-p, 75 ohms unbalanced,
sync negative
S video:
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
C: same level as that of the chroma signal of
composite video
R/G/B: 1 Vp-p, 75 ohms unbalanced, sync
negative (with sync ON)
Component video:
Y: 1 Vp-p, 75 ohms unbalanced, sync negative
Cr/Cb: 0.7 Vp-p
Sync: 2 Vp-p, 75 ohms unbalanced, sync negative
Power supply 12 V DC (supplied from the camera or the Optical
Multiplex Unit)
Power consumption 3.7 W max.
Operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating humidity 20% to 80% (no condensation)
Storage temperature –20 °C to +60 °C (–4 °F to +140 °F)
Storage humidity 20% to 95% (no condensation)
Dimensions 134 × 25.6 × 74.6 mm (w/h/d)
(5
3
/ 8× 1
1
/ 16 × 3 inches)
(not including the projected parts)
Mass Approx. 125 g (4.4 oz)
Supplied accessories Operating Instructions (1)
Design and specifications are subject to change without notice.
Pin assignments of RGB/SYNC connector
(D-sub 9-pin)
Pin No. Function
1 GND
2 GND
3 R/Cr
4 G/Y
5 B/Cb
6 Composite video/Y
7 SYNC
8 GND
9 – /C

Français
La carte d’interface BRBK-SA1 est exclusivement destinée à être
utilisée avec la caméra vidéo couleur HD BRC-Z330 Sony ou le
module multiplex optique HD BRU-SF10 Sony.
La BRBK-SA1 convertit l’image prise avec la caméra en un signal de
sortie vidéo composite, S-vidéo, RVB ou vidéo composantes. Le
signal de sortie peut être sélectionné avec le menu de la caméra.
Pour l’installation de la carte d’interface et les opérations après
l’installation, consultez le mode d’emploi de la caméra ou du module
multiplex optique.
Pour les clients au Canada
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
Pour les clients en Europe, Australie et Nouvelle-
Zélande
AVERTISSEMENT
Il s’agit d’un produit de Classe A. Dans un environnement
domestique, cet appareil peut provoquer des interférences
radio, dans ce cas l’utilisateur peut être amené à prendre des
mesures appropriées.
Si des interférences se produisent, contactez votre service
après-vente agréé Sony.
Pour les clients en Europe
Le fabricant de ce produit est Sony Corporation, 1-7-1 Konan,
Minato-ku, Tokyo, Japon.
Le représentant autorisé pour EMC et la sécurité des produits
est Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Allemagne.
Ne pas utiliser cet appareil dans une zone résidentielle.
Spécifications
Connecteur de sortie Vidéo : type BNC (1)
S-vidéo : Mini-DIN à 4 broches (1)
RVB/SYNC : D-sub 9 broches (1)
Signal de sortie Vidéo composite : 1 Vc-c, 75 ohms,
asymétrique, sync négative
S-vidéo :
Y : 1 Vc-c, 75 ohms, asymétrique, sync
négative
C : même niveau que celui du signal de
chrominance du signal de sortie vidéo
composite
R/G/B : 1 Vc-c, 75 ohms, asymétrique,
sync négative (avec sync activé)
Vidéo composantes :
Y : 1 Vc-c, 75 ohms, asymétrique, sync
négative
Cr/Cb : 0,7 Vc-c
Sync : 2 Vc-c, 75 ohms, asymétrique, sync
négative
Alimentation 12 V CC (fournie par la caméra ou le
module multiplex optique)
Puissance consommée 3,7 W maximum
Température de fonctionnement
0 °C à 40 °C (32 °F à 104 ºF)
Humidité de fonctionnement
20% à 80% (sans condensation)
Température de stockage –20 °C à +60 °C (–4 °F à +140 ºF)
Humidité de stockage 20% à 95% (sans condensation)
Dimensions 134 × × 25,6 74,6 mm (l/h/p)
(5
3
/ 8× 1
1
/ 16 × 3 pouces)
(pièces saillantes non comprises)
Poids 125 g (4,4 oz) environ
Accessoires fournis Mode d’emploi (1)
La conception et les spécifications sont susceptibles d’être modifiées
sans préavis.
Brochage du connecteur RVB/SYNC (D-sub 9 broches)
N° de broche Fonction
1 GND
2 GND
3 R/Cr
4 G/Y
5 B/Cb
6 Vidéo composite/Y
7 SYNC
8 GND
9 – /C
Español
La tarjeta de interfaz BRBK-SA1 ha sido diseñada para ser utilizada
exclusivamente con la videocámara a color Sony BRC-Z330 HD o la
unidad múltiplex óptica HD Sony BRU-SF10.
La BRBK-SA1 convierte la imagen tomada con la cámara en señal de
video compuesto, señal S video, señal RGB o señal de vídeo
componente que se quiera sacar. La señal de salida puede
seleccionarse con el menú de la cámara.
Para la instalación de la tarjeta de interfaz y las operaciones después
de haberla instalado, consulte el Manual de instrucciones suministrado
con la cámara o la unidad múltiplex óptica.
Para los clientes de Europa, Australia y Nueva
Zelanda
ADVERTENCIA
Éste es un producto de clase A. En un ambiente doméstico,
este producto puede causar interferencias radioeléctricas, en
cuyo caso el usuario puede tener que tomar las medidas
adecuadas.
En el caso de que se produzcan interferencias, póngase en
contacto con el centro de asistencia autorizado de Sony más
cercano.
Para los clientes de Europa
El fabricante de este producto es Sony Corporation, con
dirección en 1-7-1 Konan, Minato-ku, Tokio, Japón.
El Representante autorizado para EMC y seguridad del
producto es Sony Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Alemania.
Este dispositivo no debe utilizarse en zonas residenciales.
Especificaciones
Conector de salida Vídeo: Tipo BNC (1)
S vídeo: DIN mini de 4 clavijas (1)
RGB/SYNC: D-sub 9 terminales (1)
Señal de salida Vídeo compuesto: 1 Vp-p, 75 ohmios
desbalanceada, sincronización negativa
S vídeo:
Y: 1 Vp-p, 75 ohmios desbalanceada,
sincronización negativa
C: el mismo nivel que el de la señal de
cromancia de vídeo compuesto
R/G/B: 1 Vp-p, 75 ohmios desbalanceada,
sincronización negativa (con
sincronización activada)
Vídeo componente:
Y: 1 Vp-p, 75 ohmios desbalanceada,
sincronización negativa
Cr/Cb: 0,7 Vp-p
Sincronización: 2 Vp-p, 75 ohmios
desbalanceada, sincronización negativa
Alimentación 12 V CC (suministrados desde la cámara o
la unidad múltiplex óptica)
Consumo 3,7 W máx.
Temperatura de funcionamiento
0 °C a 40 °C (32 °F a 104 °F)
Humedad de funcionamiento
20% a 80% (sin condensación)
Temperatura de almacenamiento
–20 °C a +60 °C (–4 °F a +140 °F)
Humedad de almacenamiento
20% a 95% (sin condensación)
Dimensiones 134 25,6 74,6 mm (an/al/prf)× ×
(5
3
/ 8× 1
1
/ 16 × 3 pulgadas)
(sin incluir las partes salientes)
Peso Aprox. 125 g (4,4 oz)
Accesorios suministrados Manual de instrucciones (1)
El diseño y las especificaciones están sujetos a cambios sin previo
aviso.
Asignación de terminales del conector RGB/SYNC
(D-sub 9 terminales)
Número de terminal Función
1 GND
2 GND
3 R/Cr
4 G/Y
5 B/Cb
6 Vídeo compuesto/Y
7 SYNC
8 GND
9 – /C
Product specificaties
Merk: | Sony |
Categorie: | Niet gecategoriseerd |
Model: | BRBK-SA1 |
Kleur van het product: | Zwart |
Intern: | Ja |
Hostinterface: | USB |
Output interface: | S-Video, Serial, VGA |
Heb je hulp nodig?
Als je hulp nodig hebt met Sony BRBK-SA1 stel dan hieronder een vraag en andere gebruikers zullen je antwoorden
Handleiding Niet gecategoriseerd Sony
28 Juli 2025
8 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
7 Juli 2025
Handleiding Niet gecategoriseerd
- Discovery
- Medisana
- Echo
- Total Chef
- Argus
- Satco
- RAVPower
- Cateye
- Lynx
- Astropet
- KoolScapes
- 3 Legged Thing
- VAX
- Ambient Weather
- Grüniq
Nieuwste handleidingen voor Niet gecategoriseerd
31 Juli 2025
31 Juli 2025
31 Juli 2025
31 Juli 2025
31 Juli 2025
31 Juli 2025
30 Juli 2025
30 Juli 2025
30 Juli 2025
30 Juli 2025
