Ultra 7 Quick Start Guide

Rugged, powerful, and feature-rich, the Ultra 7 offers 2300 nits of brightness, 6G SDI that allows you

to ingest 4K signal, a 2-pin power passthrough for cleaner builds, an Ethernet port for camera

control, plus a joystick and tactile physical buttons for control in any conditions. Utilize all your

favorite PageOS tools, functions, and settings pages on a fully loaded 7-inch touchscreen monitor.

SmallHD User Manual

Page 1Ultra 7 Quick Start Guide

TABLE OF CONTENTS

1. ACTIVATE WARRANTY ............................................................................................................................... 3

2. PHYSICAL PROPERTIES ............................................................................................................................. 3

3. POWER AND CONNECT .............................................................................................................................. 4

4. PAIRING

5. PAGEOS OVERVIEW .................................................................................................................................... 6

• General Layout ...................................................................................................................................... 6

• Basic Navigation ................................................................................................................................... 7

• Input and Output .................................................................................................................................. 11

• Display .................................................................................................................................................. 11

• Controls ................................................................................................................................................ 12

• Capture ................................................................................................................................................. 13

• Interface ............................................................................................................................................... 13

• User ...................................................................................................................................................... 14

• System ................................................................................................................................................. 15

6. ADDITIONAL RESOURCES AND FCC RULES/REGULATIONS ................................................................ 16
