Pagina 1/237

503/703 ULTRABRIGHT

/703 BOLT USER GUIDE

Table of Contents

Regulatory Information ..................................................................................................................................... 4

Legal Information .................................................................................................................................. 5

User Interface .................................................................................................................................................... 6

User interface quick-start (joystick) ..................................................................................................... 7

Working with Pages ............................................................................................................................ 13

Output Page ......................................................................................................................................... 14

Multi-View Page .................................................................................................................................. 15

Pixel Zoom ........................................................................................................................................... 16

Settings Menu ................................................................................................................................................. 19

Tutorial for Joystick Monitors (section) ............................................................................................ 20

Input/Output ........................................................................................................................................ 21

Wireless Pairing .................................................................................................................................. 28

Display ................................................................................................................................................. 34

Controls ............................................................................................................................................... 40

Capture ................................................................................................................................................ 48

Accessories ......................................................................................................................................... 51

Interface ............................................................................................................................................... 53

User ...................................................................................................................................................... 57

System ................................................................................................................................................. 60

Tools - Framing ............................................................................................................................................... 62

Aspect (guides) ................................................................................................................................... 63

Safe (guides) ....................................................................................................................................... 68

Crosshair ............................................................................................................................................. 71

Crosshatch .......................................................................................................................................... 73

Tools - Exposure .............................................................................................................................................. 75

Exposure Assist (False Color) ............................................................................................................ 76

Zebra .................................................................................................................................................... 96

Color Picker .......................................................................................................................................104

SmallHD User Manual

Product specificaties

Merk:	SmallHD
Categorie:	Monitor
Model:	MON-703BOLT
Kleur van het product:	Zwart
Gewicht:	850.48 g
Breedte:	30.7 mm
Diepte:	213.4 mm
Hoogte:	124.5 mm
Gewicht verpakking:	2211.26 g
Beeldschermdiagonaal:	7.02 "
Resolutie:	1920 x 1080 Pixels
Touchscreen:	Nee
Pixeldichtheid:	323 ppi
Ondersteunde video-modi:	480i, 576i, 720p, 1080i, 1080p
Kijkhoek, horizontaal:	178 °
Kijkhoek, verticaal:	178 °
Compatibele geheugenkaarten:	SD
Typische contrastverhouding:	1150:1
Helderheid:	3000 cd/m²
LED backlight:	Ja
Vermogensverbruik (max):	16.7 W
Formaat analoog signaal:	NTSC, PAL
Display technologie:	IPS
Beeldverhouding:	16:9
Ingangsspanning:	12 - 34 V
Soort voeding:	Batterij/DC
Temperatuur bij opslag:	-20 - 48 °C
Hoofdtelefoon uit:	Ja
Netstekker:	Ja
Bedrijfstemperatuur (T-T):	-17 - 37 °C
Aantal geheugenslots:	1
USB 2.0 aansluitingen:	1
Audiosamplefrequentie:	48 kHz
Aantal monitoren:	1
