HDMI 2.0 8x8 Matrix Switcher

User Manual

4K 8x8 HDMI2.0 Matrix Switcher

Preface

Read this user manual carefully before using the product. Pictures shown in this manual

is for reference only. Dierent models and specications are subject to real product.

This manual is only for operation instruction only. The functions described in this version

are updated till December 11, 2016. In the constant effort to improve our product, we

reserve the right to make functions or parameters changes without notice or obligation.

Please refer to the dealers for the latest details.

Trademarks

Any other trademarks mentioned in this manual are acknowledged as the properties of

the trademark owner. No part of this publication may be copied or reproduced without the

prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to

radio communications. It has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a commercial installation.

Operation of this equipment in a residential area is likely to cause interference, in which

case the user at their own expense will be required to take whatever measures may be

necessary to correct the interference

Any changes or modications not expressly approved by the manufacture would void the

user’s authority to operate the equipment.

4K 8x8 HDMI2.0 Matrix Switcher

SAFETY PRECAUTIONS

To insure the best from the product, please read all instructions carefully before using the

device. Save this manual for further reference.

 Unpack the equipment carefully and save the original box and packing material for

possible future shipment

 Follow basic safety precautions to reduce the risk of re, electrical shock and injury to

persons.

 Do not dismantle the housing or modify the module. It may result in electrical shock or

burn.

 Using supplies or parts not meeting the products’ specifications may cause damage,

deterioration or malfunction.

 Refer all servicing to qualied service personnel.

 To prevent re or shock hazard, do not expose the unit to rain, moisture or install this

product near water.

 Do not put any heavy items on the extension cable in case of extrusion.

 Do not remove the housing of the device as opening or removing housing may

expose you to dangerous voltage or other hazards.

 Install the device in a place with ne ventilation to avoid damage caused by overheat.

 Keep the module away from liquids.

 Spillage into the housing may result in re, electrical shock, or equipment damage. If

an object or liquid falls or spills on to the housing, unplug the module immediately.

 Do not twist or pull by force ends of the optical cable. It can cause malfunction.

 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to

the device before cleaning.

 Unplug the power cord when left unused for a long period of time.

 Information on disposal for scrapped devices: do not burn or mix with general

household waste, please treat them as normal electrical wastes.

Product specificaties

Merk:	SIIG
Categorie:	Schakelaar
Model:	CE-H23X11-S1
Soort bediening:	Knoppen
Ingebouwd display:	Ja
Gewicht:	1982 g
Breedte:	437 mm
Diepte:	236 mm
Hoogte:	44 mm
Gebruikershandleiding:	Ja
Materiaal behuizing:	Metaal
USB-connectortype:	Micro-USB
Meegeleverde kabels:	IR, RS-232
Inclusief AC-adapter:	Ja
Kleur behuizing:	Zwart
Aantal USB-aansluitingen:	1
Certificering:	FCC, CE
HDCP:	Ja
HDR-ondersteuning:	Ja
Aansluiting voor netstroomadapter:	Ja
3D:	Ja
HDMI versie:	2.0
Aantal HDMI-invoerpoorten:	8
Remote (IR) ingang:	1
Duurzaamheidscertificaten:	RoHS
Temperatuur bij opslag:	-20 - 60 °C
Upgraden van firmware mogelijk:	Ja
Web-gebaseerd management:	Ja
Output current:	2710 mA
Spanning:	24 V
HDCP versie:	2.2
Montagebeugels meegeleverd:	Ja
RJ-45 invoer ports:	1
Aantal HDMI-uitvoerpoorten:	8
Afstandsbediening inbegrepen:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 90 procent
Type product:	AV-matrixschakelaar
Type beeldscherm:	LCD
Vermogenstoevoer locatie:	Extern
Extended display identification data (EDID):	Ja
