QUICK STEP STAND BASE
SETUP & USAGE
1.
2.
3.
4.5.
®
1) Attach a light or other support gear using a standard 5/8” adapter or baby pin by placing it inside the middle receiver and
tightening the thumb screw on the side.
2) While holding on to the light or other support mounted, press the foot pedal to reposition to the angle of your choice, then
release the pedal fully to lock in place.
3) Use sandbags over the base legs, or bolt to the oor using the 3/8” threads located at the front of each leg, for weight
exceeding 1.6 lbs. (0.73kg) when using a 40” (102cm) gobo arm.
4) Ball head will hold 8 lbs. (3.63kg) without slipping using a standard 40” gobo arm.
5) To decrease/increase the tension and capacity of the ball head, loosen/tighten using using the included no. 6 allen wrench
on the bottom of the stand base beneath the ball head.
PRESS FOOT PEDAL TO ADJUSTANCHOR TO FLOOR OR USE SANDBAGS
BALL HEAD CAN SUPPORT UP TO 8LBSADJUST TENSION USING ALLEN WRENCH
ATTACH GRIP ARM OR LIGHT TO RECEIVER
Thank you for purchasing the Savage Quick Step Stand Base.
Please read this instruction manual before use, and keep for later reference.
professionalphotographymadesimple
800.624.8891 savageniversalcomU.
