Pagina 1/9

CLASS 320 KISTOCK DATA LOGGERS
Quick Start Guide
KT320 / KTT320 / KCC320 / KPA320 / KP320 / KP321
EN FR ES ZH
Kimo, a Sauermann brand.
sauermanngroup.com

English
Quick start guide
Operating temperature, protection of the instruments and information about storage and the battery
1 Display
•
Operating temperature*:
KT320: from -40 to +70 °C / -40 to +158 °F; KTT320: from -20 to +70 °C / -4 to +158 °F;
KCC320, KPA320, KP320 & KP321: from 0 to 50 °C / 32 to 122 °F
• KT320: IP65; KTT320: IP54; KCC320, KPA320: IP40, KP320, KP321: IP65*
• Storage temperature: from -20 to +50 °C / -4 to 122 °F
Battery power supply: 2 x lithium AA 3.6 V batteries
*With the pressure connectors plugged
2 Dimensions (mm)
Reference Parameters
KT 320 Temperature, humidity, current, voltage, electric pulses
KTT 320 Temperature
KCC 320 Temperature, humidity, atmospheric pressure, CO
2
KPA 320 Temperature, humidity, atmospheric pressure
KP320, KP321 Differential pressure
°C: Temperature in °Celsius.
°F: Temperature in °Fahrenheit
%RH: Relative humidity
DATASET is nished.
Indicates that one value is being recorded.
It ashes: the DATASET did not start already.
Flashing slowly: DATASET is between 80 and 90% of the storage capacity.
Flashing quickly: DATASET is between 90 and 100% of the storage capacity.
Constant: storage capacity full.
Constant: indicates that the batteries have to be replaced.
Indicates the channel number which is measuring.
Screen actualisation of measured values.
The displayed values are the maximum/minimum values recorded
for the channels displayed.
Indication of the direction of exceeding the threshold in the
recorded measurement
REC
END
BAT
ACT
MIN
MAX
1 2
3 4
FULL
KT320 KTT320 KCC320, KPA320
KP320, KP321

6 Mounting
7 Accessories
Please refer to the data sheet to get more information about available accessories.
Maintenance: please avoid any aggressive
solvent. Please protect the device from any
cleaning product containing formalin, that
may be used for cleaning rooms or ducts.
Precautions for use: please always use the de-
vice in accordance with its intended use and within
parameters described in the technical features in
order not to compromise the protection ensured by
the device.
Safety lock wall mount with padlock
Mount the safety lock support on the required place.
1. Present the KISTOCK data logger on the support starting with the inferior part
2. Clip the KISTOCK on the support by falling back the superior part
3. Insert the padlock to ensure the safety lock function
The padlock can be replaced by a fail-safe sealed.
The data logger can be placed on the screw-mount without the safety lock function.
• To remove the data logger from the support, proceed on reverse order.
The system allows to secure your KISTOCK data logger on sensitive sites.
Dimensions of the wall mount (mm)
Front view
74 mm / 2 58/64
85 mm / 3 22/64’’
112 mm / 4 26/64’’
25 mm
63/64’’
69.5 mm / 2 47/64’’
39 mm
1 34/64’’
4.5 mm
11/64’’
Side view
31.5 mm
1 15/64’’
