Tachometer

USER MANUAL

Description of the device

1. OK key

2. Backlight key

3. Select key

4. On/Off/Esc key

5. Hold/min/max key

CT 110

Technical specications

Measuring elements

Optical tachometry: optical detection (Phototransistor sighting distance max. 40 cm)

Contact tachometry: ETC adaptator for optical tachometry probe

Display

4 lines, LCD technology. Dimensions: 50 x 36 mm

2 lines of 5 digits with 7 segments (value)

2 lines of 5 digits with 16 segments (unit)

ConnectorCoiled, 0.45 m length, extension: 2.4 m

HousingABS, protection IP54

Keypad5 keys

European directives2014/30/EU EMC; 2014/35/EU Low Voltage; 2011/65/EU RoHS II; 2012/19/EU WEEE

Power supply 4 batteries AAA LR03 1.5 V

AmbienceNeutral gas

Conditions of use (°C, %RH, m)From 0 to +50 °C. In non condensing conditions. From 0 to 2000 m.

Storage temperature From -20 to +80 °C

Auto shut-offAdjustable from 0 to 120 min

Weight190 g

General features

ParametersMeasuring unitsAccuracy

(1)

Measuring rangeResolution

Optical tachometerrpm

From 60 to 10 000 rpm:

±0.3% of reading ±1 rpm

From 10 001 to 60 000 rpm: ±30 tr/min

From 60 to 60 000 rpm1 rpm

Contact tachometer

rpm, m/min,

ft/min, in/min, m/s

From 30 to 3000 rpm:

±1% of reading ±1 rpm

From 30 to 3000 rpm1 rpm

(1)

All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
