WARNING: Risk of Fire or Electric Shock

• Disconnect power before installation or any maintenance

of the xture.

• To avoid damage, falling, electric shock or re, do not modify the xture

or replace accessories without conrming with the supplier rst.

• Only authorized, qualied personnel should install this xture and should

follow the owner’s manual.

• Do not dismantle the xture without the supplier’s authorization.

• Do not touch the power supply when the xture is operating.

• For use in environments where an accumulation of non-conductive dust

on the xture may be expected.

• Suitable for indoor/outdoor installations.

• For use with minimum 90°C supply conductors.

IMPORTANT: Consult a qualied electrician to ensure correct branch circuit

conductor is used. This product must be installed in accordance with the

applicable installation code by a person familiar with the construction and

operation of the product and the hazards involved.

LED CCT DIRECTIONAL LOW PROFILE

DOWNLIGHTS, FLAT LENS, REMOTE DRIVER

Models: S11878, S11879

Satco Products, Inc.

Brentwood, NY 11717

INSTALLATION

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

© Copyright 2023 Satco Products, Inc. 7/23 v1.3

ModelDecriptionWatts VoltsCCTCRIFinish

S118784" Round11W

120V27K,30K,35K,40K,50K90White

S118796" Round14W

Fixture Includes:

1 LED Lamp

1 Junction Box

TOOLS REQUIRED: Hole saw, measuring tape and connector cables

(as needed).

NOTE: Use extensions if necessary. Available connector cables are

6' (1.8m). Connector cables are linkable.

1. Turn power OFF from the electrical panel before starting installation.

2. Cut a hole in the ceiling for the downlight in a suitable position. Refer to

Hole Cut Dimensions chart (below).

3. Run the electrical wire from the switch (power supply wire) through the

mounting hole. Use NMD90 Romex or BX cable. See Figure A.

4. Open the Junction Box swing cover and remove the appropriate knockouts.

5. Insert the power supply wire through the knockout and fasten with a cable

connector (not included).

6. Connect wires inside the Junction Box using the quick connect terminals.

Connect green ground with the green box wire. Connect the black and white

power leads with the matching black and white box wires. See Wiring Diagram.

7. Put all wires and connections back into the box and close the cover securely.

8. New Construction Applications: Junction Box shall be firmly secured

to the studs, joists or similar fixed structural units.

Remodel Applications: Do not require the Junction Box to be firmly secured

to xed structural units.

9. Choose desired color temperature. See Figure B.

10. Bend back the two torsion springs and slowly t the xture through the ceiling

hole. The torsion springs will pull the xture into place. See Figure C.

11. Once installation is complete,

turn power ON to conrm the

xture is working properly.

Hole Cut Dimensions:

4" Round: ø110mm (4-3/8")

6" Round: ø160mm (6-1/4")

Cable to fixture

Power supply

Green wires

White wires

Black

wires

Quick connect

terminals

WIRING DIAGRAM

Figure A

Figure B

Figure C

Features:

4" or 6" Gimbal

with frosted lens
