WARNING: Risk of Fire or Electric Shock

• Disconnect power before installation or any maintenance of

the xture.

• To avoid damage, falling, electric shock or re, do not modify the xture

or replace accessories without conrming with the supplier rst.

• Only authorized, qualied personnel should install this xture and

should follow the owner’s manual.

• Do not dismantle the xture without the supplier’s authorization.

• Do not touch the power supply when the xture is operating.

• For use in environments where an accumulation of non-conductive

dust on the xture may be expected.

• Suitable for indoor/outdoor locations.

IMPORTANT: This product must be installed in accordance with the

applicable installation code by a person familiar with the construction

and operation of the product and the hazards involved.

LED EDGE LIT 4"&6"

RECESSED DOWNLIGHTS

Models: S11690, S11691

Satco Products, Inc.

Brentwood, NY 11717

INSTALLATION

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

© Copyright 2024 Satco Products, Inc. 12/24 v3.0

ModelDimensionsShape

Watts

Selectable

VoltsCCT SelectableCRIFinish

S116904 inchesRound8W–12W

120V-

277V

2700K, 3000K, 3500K,

4000K, 5000K

90White

S116916 inchesRound11W–15W

TOOLS REQUIRED: Hole saw, measuring tape and connector cables (as needed).

NOTE: Use extensions if necessary. Available connector cables are 6' (1.8m).

Connector cables are linkable for greater remote mounting distances. Contact

the factory for maximum distance.

1. Turn power OFF from the electrical panel before starting installation.

2. Cut a hole in the ceiling for the downlight in a suitable position. Refer to Hole Cut

Dimension chart (below).

3. Run the electrical wire from the switch (power supply wire) through the mounting hole.

See Figure A.

4. Open the Junction Box swing cover and remove the appropriate knockouts.

5. Insert the power supply wire through the knockout and fasten with a cable connector

(not included).

6. Connect wires inside the Juction Box using the quick connect terminals. Connect power

supply ground with the Junction Box Ground Wire. Connect the black and white power

leads with the matching black and white box wires. See Wiring Diagram.

7. Put all wires and connections back into the box and close the cover securely.

8. New Construction Applications: Juntion Box shall be firmly secured to the studs,

joists or similar fixed structural units.

Remodel Applications: The junction box is not required to be firmly secured to xed

structural units.

9. Set color temperature with CCT switch: 2700K/3000K/3500K/4000K/5000K. Insert

the junction box into the ceiling. See Figure B.

10. Set the wattage with the power switch before inserting the junction box into the ceiling.

See Figure C.

11. Bend back the two torsion springs and slowly t the xture through the ceiling hole.

The spring clips will pull the xture into place. See Figure D & E.

12. Once installation is complete, turn power ON to conrm the xture is working properly.

Hole Cut Dimensions: 4" xture = ø 4 1/4" (108mm), 6" xture = ø 6 3/16" (157mm)

Fixture Includes: 1 LED Lamp, 1 Junction Box

Figure C

Figure B

Figure A

Figure D

Figure E
