1

LED T8 REPLACEMENT LAMPS

Models: S11757

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

Item Number-Description

Minimum Lamp

Compartment Dimensions

(Length x Width x Height) (cm)

Lamp

Quantity

Lamp-to-Lamp

Spacing (cm)

S11757-40T8/LED/96-CCT/BP/R2PC/1PK244 x 27 x 7211

WARNING:

• DANGER: Risk of shock-disconnect power before

installation.

• WARNING: Risk of re or electric shock. LED

Retrot Kit installation requires knowledge of luminaire

electrical systems. If not qualied, do not attempt

installation. Contact a qualied electrician.

• WARNING: Product must be installed in accordance

with the national electrical code or your local electrical

code. If you are not familiar with these codes and

requirements, contact a qualied electrician.

• WARNING: Install this kit only in luminaries that have

the construction features and dimensions shown in the

photographs and/or drawing and where the input rating

of the retrot kit does not exceed the input rating of

the luminaire.

• WARNING: To prevent wiring damage or abrasion,

do not expose wiring to edges of sheet metal or other

sharp objects.

Do not make or alter any open holes in an enclosure of

wiring or electrical components during kit installation.

Installers should not disconnect the existing wire from

lampholder terminals to make new connections at

lampholder terminals. Instead installers should cut

existing lampholder leads away from the lampholder

and make new electrical connections to lampholder

lead wires by employing applicable connectors.

• WARNING: Luminaire wiring and electrical parts

may be damages when installing retrot kit hardware.

Check for enclosed wiring and components.

• WARNING: Risk of re or electric shock.

Installation of this retrot assembly requires a person

familiar with the construction and operation of the

luminaire’s electrical system and the hazard involved.

If not qualied, do not attempt installation. Contact a

qualied electrician.

• CAUTION:Risk of electric shock. Do not use if

outer lamp envelope is damaged or broken.

• Installers should examine all parts that are not intended

to be replaced by the retrofit kit for damage and replace

any damaged parts prior to installation of the retrofit kit.

• WARNING: Check the existing wiring for damage

before installing upgrade kit. Do not install if existing

wires are damaged.

The retrot kit is accepted as a component of a

luminaire where the suitability of the combination

shall be determined by authorities having jurisdiction.

Product must be installed by a qualied electrician

in accordance with the applicable and appropriate

electrical codes. The installation guide does not

supersede local or national regulations for electrical

installations.

Type B Lamp – intended for operation in luminaires

with traditional uorescent-type lamp holders wired

directly to the branch circuit. This includes both

factory-wired luminaries as well as those converted

for this purpose under a retrot program.

THIS RETROFIT KIT INCLUDES, LED TUBE,

OPERATING INSTRUCTIONS, AND FIXTURE LABEL

FOR THE DOUBLE OR SINGLE ENDED APPLICATION.

• “This luminaire has been modied and can no longer

operate the originally intended lamp,” shall be marked

on the retrot luminaire where readily visible by the user

during normal maintenance including lamping.

• Only use the control provided with or specied by

these instructions to control this lamp. This lamp will

not operate properly when connected to a standard

(incandescent) dimmer or dimming control. For dimming,

only operate at 120-277V with specic dimmer, Dim-mate

accessory, manufactured by Jiaxing Super Lighting.

• Suitable for damp locations.

• Suitable for use in enclosed luminaries.

• Suitable for use with the following emergency

equipment; SATCO Products, Inc., Model S8002,

10W Emergency LED Driver.

• This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) This device must accept any interference

received, including interference that may cause

undesired operation.

The units covered by this report were intended to retrot surface mount, Type IC or non-IC recessed mount Listed uorescent

luminaires that use maximum 2 tubular lamps, the minimum lamp compartment dimensions are tabulated below.

Features, applications and installation instructions

continued on pages 2-4.

Satco Products, Inc.

Brentwood, NY 11717© Copyright 2024 Satco Products, Inc. 8/24 v3.0
