RECESSED LIGHTING

ROUGH-IN PLATE KIT

Satco Products, Inc.

Brentwood, NY 11717

NEW CONSTRUCTION PLATE DRYWALL INSTALLATION – A

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

© Copyright 2020 Satco Products, Inc. 1/20

New Construction plate for stud/joist mounting, ts up to 24” studs/joist spacing.

2.

Nail or screw brackets to studs/joist. See Figure 2.

3.

Make appropriate wiring connections as required, follow downlight instructions to complete installation. See Figures 4, 5.

Model#

Rough-in

Plate Dim.

Fixture

Dim.

Compatible Satco Products

80-9623.15 x3.15 Square12"S11720

80-963

"

18"S11721

80-96424"S11722

80-96532"S11723

Fig. 1

Fig. 2

Fig. 3

Fig. 5

Fig. 4

80-96648"S11724

Model: 80-962,80-963,80-964,80-965,80-966

"

17.12 x3.15 Square

""

23.03 x3.15 Square

""

30.91 x3.15 Square

""

46.65 x3.15 Square

""

Fig. 6

1.Install the brackets to two short sides of plate. See Figure 1.
