Pagina 1/40

AC024JXADCH

AC030JXADCH

AC036JXADCH

AC042JXADCH

AC048JXADCH

AC030JXSCCH

AC036JXSCCH

AC054KXADCH

Air Conditioner

installation manual

imagine the possibilities

Thank you for purchasing this Samsung product.

Contents

PREPARATION

Safety precautions ....................................................................................................... 3

Preparation for outdoor unit installation ................................................................................. 5

Deciding on where to install the outdoor unit ............................................................................ 7

Outdoor unit installation ................................................................................................ 13

INSTALLATION

Connecting the cable ................................................................................................... 15

Connecting the refrigerant pipe ......................................................................................... 23

Adding refrigerant (R-410A) ............................................................................................. 24

Connecting to the system and removing air in the circuit ................................................................ 25

Connecting the drain hose to the outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Cutting/Flaring the pipes ............................................................................................... 28

Performing leak tests ................................................................................................... 29

Refrigerant pipe work ................................................................................................... 29

Using stop valve ........................................................................................................ 30

Interface module Installation (Optional) ................................................................................. 31

Pump down Procedure ................................................................................................. 32

Checking correct grounding ............................................................................................ 33

Testing operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Installing the wind bae ............................................................................................... 37

Troubleshooting ........................................................................................................ 38

OTHERS

IMPORTANT – This product has been designed and manufactured to meet ENERGY STAR criteria for energy eciency

when matched with appropriate coil components.

However, proper refrigerant charge and proper air ow are critical to achieve rated capacity and eciency. Installation of

this product should follow the manufacturer’s refrigerant charging and air ow instructions. Failure to conrm proper

charge and airow may reduce energy eciency and shorten equipment life.
