SALUS Controls is a member of the Computime Group

Maintaining a policy of continuous product development SALUS

Controls plc reserves the right to change specications, design and

materials of products listed in this brochure without prior notice.

SALUS Controls plc,

Units 8-10,

Northeld Business Park,

Forge Way, Parkgate

Rotherham, S60 1SD

SALUS Controls GmbH,

Dieselstrasse 34,

63165 Mühlheim am Main,

Germany

Quick Guide

UK: [email protected]

DE / NL: [email protected]

PL: [email protected]om

FR: [email protected]

RO: tehnic@saluscontrols.ro

DK: Suppor[email protected]

V02

03/2025

www.saluscontrols.com

091PRO-RF

PROGRAMMABLE THERMOSTAT

MULTI-LANGUAGE

MANUAL

Refer to the wiring diagrams for proper receiver installation.

This product complies with the essential requirements and other relevant

provisions of Directives: 2015/863/EU, 2014/53/EU

868.0 MHz <13dBm

The full text of the EU Declaration of Conformity is available at the following

internet address: www.saluslegal.com

Product Compliance

Introduction

The 091PRO-RF is a programmable weekly controller designed to regulate

the temperature of heating or cooling systems. It operates on AA, 1.5V

alkaline batteries, which must be inserted into the compartment under the

ap. Rechargeable batteries are not supported.

Additionally, the device features a that can be activated based Boost Mode

on , ensuring optimal comfort and eciency.motion detection

Full manual available on our website.

4 x Screws4 x Wall AnchorsNC-NO CablePower Cable

2 x AA

Batteries

Buttons & description

Icons and Display

Wiring Diagram

Use in accordance to national and EU regulations. Use the device as intended,

keeping it in dry condition. Product for indoor use only. Installation must

be carried out by a qualied person in accordance to national and EU

regulations.

Safety Information

1234567

8

9

10

11

12

13

14

15

16

17

18

19

1. Settings

2. Motion detection

3. RF Status

4. Child protection

5. Cooling mode

6. Heating mode

7. Comfort mode

8. Economic mode

9. Frost protection mode

10. Holiday mode

11. Party mode

12. Manual mode or

Temporary override

13. AM / PM

14. Personalised time indicator

15. Low battery indicator

16. Hourly program indicator

17. Clock

18. Day of the week

19. Room or Setpoint temperature

1.Comfort Setting or Temperature UP

2.Set the day (), hour () and DH

minute (M)

3.ComfortEconomy Set or

temperature

4.Weekly Program setting

5. New Program Mode or Program

Selection

6.Service Conrm functionor

Menu

7.Setting Economic Mode or

Temperature DOWN

OK

SETUP

MODE

PROG #

PROG

TEMP

BACK

3

2

4

5

6

7

1

RF

ONOFF

AUTOMANUAL

Follow the steps on page 2 to re-pair your thermostat and receiver

in case of need.

Mode Selection

Mode selection allows users to cycle through dierent operating modes

of the 091Pro-RF(TX), each tailored for specic situations.

Party Mode

Manual Mode

Frost Protection Mode

Holiday Mode

Press the

TEMP

BACK

button.

Press

or buttons to

adjust setpoint temperature.

Press

OK

SETUP

to conrm.

Change Setpoint Temperature

OK

SETUP

P

PRG

TEMP

BACK

OK

SETUP

MODE

PROG #

PROG

TEMP

BACK

Receiver

RXRT55R0XRT550

Receiver

Thermostat

091Pro-RF(TX)

COM

L

L

M

N

N

NO

or

MAX

16 (5) A

L

L

NO

N

N

COM

Thermostat

091Pro-RF(TX)

Press the

MODE

PROG #

button to open

Mode Selection.

O

SE

MODE

PROG #

PROG

TEMP

BACK

Press

MODE

PROG #

again to cycle

through modes, then press

OK

SETUP

to conrm.

OK

SETUP

MODE

PROG #

PROG

TEMP

BACK

Frost protection prevents the temperature from dropping below a safe

level, helping to avoid freezing temperatures and maintain minimal

heating when the system is o.

Frost Protection Mode

091Pro-RF(TX)

Thermostat

RXRT550

Receiver

Screw Mounting

Template

The thermostat and receiver come pre-paired from the factory, so no

setup is needed.

First Power Up

Once you turn on the thermostat and receiver, they will pair

automatically.

When powering on the receiver, check the RF LED color and

blinking pattern to determine the RF signal quality. Refer below for

explanation of each LED color and pattern.

RF

RXRT550

RF

No RF signal

-

R

-

Weak RF signal

RF

-

Good RF signal

Position the thermostat and receiver within reliable RF range (RF LED

color ) to ensure correct operation.green

Hourly Program Modeor

Personalised Time Program Mode

OR

RF

-

Waiting for RF signal
