SweetSpot™ Speakers
INSTALL INSTRUCTIONS
© 2021 MSE Audio. Rev. 02.19.2021
Ultra-Fidelity Outdoor Speakers
Contact: MSE Audio, 855.663.5600 / 913.663.5600 / [email protected]
Please read the following instructions carefully before installing
your Rockustics
®
Sweetspot™ speaker. If you have any questions
regarding installation that are not answered in the following
directions, please contact your local sound contractor or the
Rockustics
®
/MSE Audio
®
technical support team.
Rockustics Sweetspot speakers are designed to combine
a stereo signal (left and right channel) into a single speaker
to provide a full audio experience from one speaker. The
Sweetspot speakers are equipped with dual voice coil woofers
and dual tweeters so they can merge left and right signal inputs
into great sounding audio from a single unit. Sweetspot models
are ideal for places where there is not enough room for stereo
speakers - or where it is impractical to use stereo speakers due
to the installation constraints.
Basic Wiring
1) Locate the speaker wires on the underside of the speaker.
If necessary, strip and trim the wire ends.
2) Connect the two speaker wire channels to the input signal
wire ():Diagram A
Channel 1: Red = positive, Black = ground
Channel 2: Blue = positive, Brown = ground
3) Use the supplied silicone wire nut to connect the leads.
Rockustics recommends using 14ga or heavier Direct
Burial cable for the connection between the amplier and
the speakers.
NOTE: The provided wire nuts are meant for permanent instal-
lation use only. If you are temporarily wiring the speakers, do not
use these wire nuts. In the event you have used the wire nuts, and
need to re-wire your system, do not attempt to unscrew the nuts.
Instead, clip the wires below the nut, and follow the steps in the
Basic Wiring section with a new pair of waterproof wire nuts (these
are available at most hardware stores).
Planter Set Up
(Diagram B) Fill planter with pea-gravel to approximately 2”
above the black insert box to ensure proper drainage. Gently
rock the planter from side to side so that gravel lles in the
gaps, providing ample coverage of the black insert box. Af-
ter lling with pea-gravel, top with soil, and continue planting
as you would any normal planter. Be sure to use the proper
amount of pea-gravel and soil to ll the planter; the soil and
gravel are important to the acoustic properties of the planter
and assist with the proper bass reproduction.
Diagram A
Diagram B
