AssemblyInstructionSheet#IS-RNL1908WT
ForStyleRNL1908WT
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
,.
..
PackageContents
HardwareContents
AA
BB
CC
DD
EE
FF
II
Crossbar
x1
LockWasher
x2
HexNut
x2
Nipple
x1
Canopy
ChainLoop
x1
CanopyLock
Ring
x1
CeilingCanopy
x1
GG
FixtureChain
x1
HH
QuickLink
x2
2017QuoizelInc.
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
FixtureLoop
x1
A
ReleasedDate:2017-10-17
B
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
Pleasegotoforproductcleaningtips.Gototheselection.
(1)A21MediumBaseBulb150WMaximumor
(1)MediumBaseVintageBulbisrecommendedbutnotsupplied.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
C
GlassPanel
x4
FixtureBody
x1
STEP1InstallGlassPanels
andFixtureLoop
-
A.InserttheGlassPanel(B)into
thecage.Attachthetopedgeof
theGlassPanel(B)totheslotin
thetopofthecage.Foldtabsin
thebottomedgeofthecageto
secureGlassPanels(B).
B.ThreadtheFixtureLoop(A)onto
thenippleonthetopcenterof
theFixtureBody(C)andhand
tightenuntilsnug.
Figure1
Slot
C
Cage
Tab
B
A
STEP2InstalltheCrossbartothejunctionbox-
.
A.AttachtheCrossbar(AA)totheOutletBoxwiththeheadofthe
GreenGroundScrewfacingyou.SecureitwithOutletBoxScrews
(notincluded),tightenuntilsnug
Figure2
OutletBox
OutletBoxScrew
(notincluded)
GreenGround
Screw
AA
STEP3InstalltheCanopyChainLoopandNipple-
A.ThreadoneHexNut(CC)tooneendoftheNipple(DD)untilitisat
least0.25”fromtheend.PassoneLockWasher(BB)overtheend
oftheNipple(DD)andthreadtheCanopyChainLoop(EE)ontothe
Nipple(DD).Byusingpliers,threadtheHexNut(CC)againstthe
CanopyChainLoop(EE)andhandtightenuntilsnug.
B.ThreadanotherHexNut(CC)tothemiddleoftheNipple(DD).
PlaceanotherLockWasher(BB)overtheNipple(DD)andthen
threadtheNipple(DD)intotheCrossbar(AA)untiltheNipple(DD)
isabout0.375”abovetheCrossbar(AA).
C.RemovetheCanopyLockRing(FF)fromtheCanopyChainLoop
(EE).PlacetheCeilingCanopy(II)overtheCanopyChainLoop
(EE)againsttheceilingtodeterminethecorrectpositionofthe
Nipple(DD).ThreadtheCanopyLockRingontotheCanopyChain
Loop(EE).AdjusttheNipple(DD)toallowtheCeilingCanopy(II)to
