AssemblyInstructionSheet#IS-PCSE138BN
ForStylePCSE138BN
PackageContents
B
MountingScrew
x4
InnerBackplate
x1
A
Figure1
Figure2
2017QuoizelInc.
ReleasedDate:2017-08-25
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Pleasegotoforproductcleaningtips.Gototheselection.
Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
Integrated12WLED
:LutronAYCL-153PorLutronDVCL-153P.
www.quoizel.comCare+Maintenance
ToolsRequired:
LightSource:
CompatibleDimmerSwitches
EstimatedAssemblyTime:
Preparation:
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
F
G
CurveTubes
x1
CeilingCanopy
x1
STEP1InstallCurveTubestoFixtureBody-
A.RemovelockscrewsfromthetopoftheFixtureBody(H).Attachthe
CurveTubes(G)ontothetopoftheFixtureBody(H)andalignthe
holesonthetabsoftheCurveTubes(G)tomountingholesonthe
FixtureBody(H).Securethemtogetherwithlockscrewspreviously
removed.Handtightenuntilsnugwithscrewdrivers.
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
LockScrew
C
6”Rod
x4
D
12”RodwithNipple
x2
H
FixtureBody
x1
E
12”Rod
x2
G
H
Hole
MountingHole
STEP2-InstallCeilingCanopy,RodsandFixtureBodytogether
A.DeterminetheRods(C/D/E)tobeassembledtotheFixtureBody(H)
accordingtoyourhangingheight.
B.Passthesupplywiresthroughthechosenrods(C/D/E).Threadthe
FixtureBody(H)andthechosenRods(C/D/E)together.Hand
tightenuntilsnug.
C.RemoveswivelsfromthebottomoftheCeilingCanopy(F)by
unlockinghexnutsinsideoftheCeilingCanopy(F).
D.Passsupplywiresthroughoneswivel,theCeilingCanopy(F),one
lockwasher,thelanyardandonehexnutinturn.
E.Threadswivelsontotheupperrods.Makesureswivelsareinthe
samedirectionbeforehandtightenthemuntilsnug.
F.PlacetheCeilingCanopy(F),lockwashers,lanyardandgroundwire
backontoswivelsasshown.Securethemtogetherwithhexnuts.
Tightgentlyuntilsnug.
SuggestedrodsforCeilingheight:
8’ceiling:use(1)6”rodand(2)12”rods
9’ceiling:use(2)6”rodsand(2)12”rods
C
C
D
E
H
SupplyWires
Swivel
LockWasher
Lanyard
HexNut
GroundWire
LockWasher
LockWasher
F
CeilingCanopy
HexNut
(SameDirection)
