PackageContents

E

C

Cage

x1

Tab

x2

B

Fixture

Body

x1

D

GlassShade

x1

F

LockScrew

x3

Figure3

B

C

D

F

Pleasegotoforproductcleaningtips.Gototheselection.

Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

(3)CandelabraBaseBulbs60WMaximum

30-45minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement

parts.

www.quoizel.comCare+Maintenance

ToolsRequired:

LightSource:

EstimatedAssemblyTime:

Preparation:

WarningsandCautions

AssemblyInstructionSheet#IS-MBH1911W

ForStyleMBH1911W

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

,.

..

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.

A

FixtureLoop

x1

STEP1AttachFixtureLoopto

FixtureBody

-

A.ThreadtheFixtureLoop(A)ontothe

topcenteroftheFixtureBody(B)and

handtightenuntilsnug.

Figure1

A

B

STEP2-InstallBulbs

A.Insertbulbsontosocketsand

screwsnuglyintoplace.

Bulb(not

supplied)

Socket

Figure2

E

HardwareContents

AA

Crossbar

Assembly

x1

BB

CC

Ceiling

Canopy

x1

FixtureChain

x1

QuickLink

x2

DD

2017QuoizelInc.

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184

orvisituson-lineatwww.quoizel.com

ReleasedDate:2017-08-02

STEP3-InstallShade

A.PlacetheGlassShade(D)intotheCage(E).Securebypressing

Tabs(C)ontotheCage(E)andtopedgeoftheGlassShade(D).

B.PlacethesocketsoftheFixtureBody(B)insideoftheGlassShade

(D).AttachthefixturehoodoftheFixtureBody(B)tothetopedgeof

theCage(E).SecurethemtogetherwithLockScrews(F).Hand

tightenuntilsnugwithscrewdrivers.
