Pleasegotoforproductcleaningtips.Gototheselection.
(4)B10CandelabraBaseBulbs60WMaximum.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
WarningsandCautions
1of2
AssemblyInstructionSheet#IS-GLY5204CS
ForStyleGLY5204CS
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
,.
..
2016QuoizelInc.
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
PackageContents
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
A
FixtureLoop
x1
B
Fixture
Body
x1
HardwareContents
AA
BB
CC
DD
EE
FF
Crossbar
x1
LockWasher
x2
HexNut
x2
Nipple
x1
Canopy
ChainLoop
x1
CanopyLock
Ring
x1
CeilingCanopy
x1
HH
QuickLink
x2
II
GG
FixtureChain
x1
Figure2
OutletBox
OutletBoxScrew
(notincluded)
GreenGround
Screw
AA
STEP2InstallCrossbar-
A.AA)AttachtheCrossbar(totheOutletBoxwiththeheadofthe
GreenGroundScrewfacingyou.SecureitwithOutletBoxScrews
(notincluded)Tightenuntilsnug..
STEP3InstallCanopyChainLoopandNipple-
*Pliersisrequiredforthisstep.
A.ThreadoneHexNut(CC)tooneendoftheNipple(DD)untilitisat
least0.25”fromtheend.PassoneLockWasher(BB)overtheendof
theNipple(DD)andthreadtheCanopyChainLoop(EE)ontothe
Nipple(DD).Byusingpliers,threadtheHexNut(CC)againstthe
CanopyChainLoop(EE)andhandtightenuntilsnug.
B.ThreadanotherHexNut(CC)tothemiddleoftheNipple(DD).Place
anotherLockWasher(BB)overtheNipple(DD)andthenthreadthe
StepB
StepA
CC
BB
EE
II
FF
AA
BB
CC
DD
Figure3
Nipple(DD)intotheCrossbar
(AA)untiltheNipple(DD)is
about0.375”abovethe
Crossbar(AA).
C.RemovetheCanopyLock
Ring(FF)fromtheCanopy
ChainLoop(EE).Placethe
CeilingCanopy(II)overthe
CanopyChainLoop(EE)
againsttheceilingto
determinethecorrectposition
oftheNipple(DD).Threadthe
CanopyLockRingontothe
CanopyChainLoop(EE).
AdjusttheNipple(DD)to
allowtheCeilingCanopy(II)
torestagainsttheceiling
whenheldinplacebythe
CanopyLockRing(FF).
D.RemovetheCanopyLock
Ring(FF)andtheCeiling
Canopy(II).TightentheHex
Nut(CC)againsttheCrossbar
(AA)tosecureinplace.
STEP1InstallFixtureLoopto
FixtureBody
-
A.ThreadtheFixtureLoop(A)ontothe
topcenteroftheFixtureBody(B).
Handtightenuntilsnug.
A
B
Figure1
STEP4-InstallFixtureChainandCeilingCanopy
A.AdjusttheFixtureChain(GG)toyourdesiredlengthbyremoving
linksifneeded.
Pliersisrequiredforthisstep.*
ReleasedDate:2016-12-07
C
Optional
CandleCover
x4
