Pagina 1/16
User Manual
Loudspeaker Range
Revela Series
Scan the QR code using a smart-phone device,
for product warranty registration online.
2
IMPORTANT SAFETY INFORMATION
Before installing this product read all these instructions!
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
Read these instructions. Keep these instructions. Heed all
warnings. Follow all instructions.
Before making any connections, switch all the units in
your system o at the mains.ff
Set the volume control at minimum when you switch on
your system or change sources, and turn the level up
gradually.
Do not use your amplifier at full volume.
Ensure that s in the system areall loudspeaker correctly
wired.
Do not subject your loudspeakers to excessive cold, heat,
humidity or sunlight.
Loudspeakers should not be placed directly facing other
hi-fi units or share the same shelf or cabinet.
Do not place heavy objects on top of loudspeakers.
Some forbid the placing of objects on topmanufacturers
of TV TVtheir sets. Check your handbook before
installing the speaker directly on your TV set. Consult
your TV dealer if you are in any doubt.
Do not connect to the mains supply.speaker terminals
Do not dismantle the loudspeaker. There are no user
serviceable parts inside it and you will void the warranty
by doing so.
Refer all service personnel.servicing to qualified
Servicing the apparatus has beenis required when
damaged in any way, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
Caution: notChanges modificationsor expressly
approved by the manufacturer could void the user's
authority to operate this device.
Unpacking Your Loudspeaker
Revela loudspeakers come in different shapes and sizes.
If you are unpacking a floor-stander, please remember
that these units are heavy. We suggest that you have
someone to assist you.
Lift the loudspeaker carefully out of the packing. Do not
try and lift the loudspeaker using the protective bag.
Unpack the accessories carefully.
If there is any sign of damage or if the contents are
incomplete, report this to your dealer as soon as possible.
Retain the packing for future safe transport of the
product. If you dispose of the packing, do so with respect
to any recycling provisions in your area.
QUAD Revela 1 bookshelf: these loudspeakers should
ideally be stand mounted though they may be placed on
a rigid shelf separate from the rest the system.
QUAD Revela 2 floor-stander: these loudspeakers are
floor-standing and should be fitted with spikes for better
stability and performance.
Attaching the Spikes to Floor-standing Model
- Revela 2
·
·
·
·
·
·
Levelling the Floor-standing Model - Revela 2
·
·
·
·
Make sure you have plenty of unobstructed working space.
Place a soft cloth on the floor to protect the loudspeaker.
Invert the loudspeaker onto the cloth.
Thread a locknut onto each spike and loosely rub it up
the thread.
Thread the spikes into the spike inserts. Tighten them
with finger tight.
Invert the loudspeaker. Be careful not to damage the
floor with the spikes.
When the speaker is upright: You will probably find
that the speaker will wobble with one spike not
contacting the floor. Adjust this spike until all four
spikes are in contact to the floor.
With the aid of a spirit level move each spike in and out
until the loudspeaker is level and sitting squarely on all
four spikes without rocking.
Now tighten each locknut securely against the collar in
the plinth to secure the spike.
Screw in rubber feet are provided for use on wood or
stone floors etc. and should be attached in the same
manner as the spikes.
IMPORTANT
SAFETY INFORMATION
PREPARING THE
LOUDSPEAKERS
CONNECTING THE
LOUDSPEAKERS
WARRANTY
COVERAGE
SPECIFICATIONS INTRODUCTION
3
INTRODUCTION
The QUAD Revela Series is a
striking new speaker series from QUAD - the originators of
‘The Closest Approach To The Original Sound’.
Revela continues the QUAD innovations laid out in recent years, taking learnings from the award-winning S-series and
Z-series whilst maintaining its strong design heritage, traceable back to 1949 and the first QUAD speaker – the Corner Ribbon.
QUAD Revela brings modern design cues coupled with the now synonymous QUAD ‘True Ribbon
TM
’ HF driver.
QUAD’s director of Acoustics, Peter Comeau, has furthered his ground-breaking engineering work in developing a new
Ribbon HF that brings a new level of musical delicacy, smoothness and hear-through performance that helps make the
music sing. The True Ribbon HF will reveal beautiful details of your music collection with a truly a breathtaking
performance.
The QUAD Revela HF is married to equally high-performance bass and midrange drivers. Using a new ‘Reveal
TM
’
advanced fibre composition, the QUAD Revela drivers have been subject to almost 3 years of continuous innovation.
Refined and further refined for seamless integration with the Ribbon HF, the smooth diaphragm drivers were purpose
selected based upon their rigidity and excellent self-damping properties. Combined with the specially developed, custom
rubber surround for a greater excursion and high-power motor system, the result is a superb bass performance, with
power, depth, speed and articulation in abundance.
And, of course, putting it all together is a phase-compensated crossover that is the result not Acoustic Butterworth
only of Computer-Aided Design but also hundreds of hours of critical listening tests using all types and flavours of
music, in order to achieve perfection.
Each QUAD Revela cabinet is skilfully hand-finished with real-wood veneers and precision-fitted baffle seamlessly joined
with a polished finish. But more than just a truly stunning furniture quality piece of craftsmanship, the cabinet is internally
braced, using a purpose engineered structure connect to the cabinet panels in a manner that dissipates unwanted
vibrations and resonances, thus maintaining structural rigidity, even under the most strenuous of performances.
Adding to the highly effective innovations in QUAD Revela, the port tube design is precisely positioned with the optimum
diameter and flaring to prevent longitudinal resonances from colouring the speaker's performance. The low and midrange
frequencies can perform with a free-flowing purity and no unintended resonance or boominess – giving you the full
dynamics of your music.
QUAD Revela Series – advanced technology, beautiful looks and breatktaking performance combined for
‘The Closest Approach To The Original Sound’.
IMPORTANT
SAFETY INFORMATION
PREPARING THE
LOUDSPEAKERS
CONNECTING THE
LOUDSPEAKERS
WARRANTY
COVERAGE
SPECIFICATIONS INTRODUCTION
