Pagina 1/177

NAS Repair Manual

Document version: 1

06/08/2024

Contents

1. Important Information

Safety information..........................................................................................................................................3

2. Introduction

NAS model categorization............................................................................................................................. 6

Repair requirements.................................................................................................................................... 10

Resources...................................................................................................................................................... 10

3. Category A NAS Models

Disassembling the TS-453E......................................................................................................................... 12

Reassembling the TS-453E...........................................................................................................................24

TS-453E components and screws............................................................................................................... 36

4. Category B NAS Models

Disassembling the TS-AI642........................................................................................................................39

Reassembling the TS-AI642.........................................................................................................................48

TS-AI642 components and screws..............................................................................................................57

5. Category C NAS Models

Disassembling the TVS-h874T.....................................................................................................................60

Reassembling the TVS-h874T......................................................................................................................78

TVS-h874T components and screws...........................................................................................................95

6. Category D NAS Models

Disassembling the TVS-h1288X...................................................................................................................98

Reassembling the TVS-h1288X..................................................................................................................119

TVS-h1288X components and screws...................................................................................................... 141

7. Category E NAS Models

Disassembling the TS-h1677AXU-RP........................................................................................................145

Reassembling the TS-h1677AXU-RP......................................................................................................... 158

TS-h1677AXU-RP components and screws..............................................................................................171

8. Glossary

air shroud.................................................................................................................................................... 174

backplane.................................................................................................................................................... 174

central processing unit (CPU)....................................................................................................................174

circuit board................................................................................................................................................ 174

CPU fan........................................................................................................................................................ 174

drive cage.................................................................................................................................................... 174

drive tray......................................................................................................................................................174

fan duct........................................................................................................................................................174

at head screw............................................................................................................................................174

heatsink....................................................................................................................................................... 175

| NAS Repair Manual

Product specificaties

Merk:	QNAP
Categorie:	Nas
Model:	TS-409U
Gewicht:	5200 g
Stroomvoorziening:	100-240V, 50/60Hz
Frequentie van processor:	0.5 GHz
Aantal USB 2.0-poorten:	3
Aantal Ethernet LAN (RJ-45)-poorten:	1
Intern geheugen:	0.5 GB
Intern geheugentype:	DDR2
Relatieve luchtvochtigheid:	0 - 95 procent
Compatibele besturingssystemen:	Win 98/ ME/ NT/ 2000/ XP/ 2003/ Vista\nMac OS X\nLinux\nUnix
Ondersteunde netwerkprotocollen:	TCP/IP, CIFS/SMB, AFP, NFS, HTTP, HTTPS, FTP, DDNS, NTP
Type behuizing:	Rack (1U)
Capaciteit opslag-drive:	4000 GB
Totale geïnstalleerde opslagcapaciteit:	4 TB
Flash memory:	8 MB
DHCP server:	Ja
Aantal storage drives geïnstalleerd:	4
DHCP client:	Ja
Afmetingen (B x D x H):	430 x 409.1 x 44.45 mm
Link/Act LED:	Ja
Opslag schijf-interface:	SATA II
Opslag schijfgrootte:	3.5 "
Jumbo Frames ondersteuning:	Ja
Bedrijfstemperatuur (T-T):	0 - 40 °C
Connectivity LEDs:	LAN/USB
