A) WIFI Module installation

1.Place the Receiver upside down on a flat surface, to expose the Receiver Screw.

2.Remove and keep the Receiver Screw (Figure 1).

3.Slide the Blank off of the Receiver and dispose of the Blank

4.Flip the Receiver over to expose the Receiver Female Connector.

5.Slide the WIFI Module Male Plug into the Receiver Female Connector to engage the Module (Figure 2).

6.With the WIFI Module Connected to the Receiver, turn the Receiver upside down on a flat surface for reinstallation

of the screw (Figure 3).

7.Reinstall the Receiver Screw into the WIFI Module to secure Module to the Receiver (Figure 3). The WIFI Module

Installation is Complete.

B) PAIRING THE HAND-HELD REMOTE CONTROL and WIFI Module

NOTE: The WIFI Module needs to be paired with the hand-held remote control. Within 60 seconds of turning the

Receiver AC power ON, press and hold the Transmitter FAN OFF(Stop) button for at least 5 seconds.The light kit will

flicker to confirm. The WIFI Module will learn the same frequency that the transmitter has set up. After completion of

above operation, you can operate the ceiling fan and light.

P2673 – DC Ceiling Fan WIFI Module

WARNING! SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
