Printed in USA 7/25/2024 1 301-500revJ-EN

LIMITED WARRANTY

This product is warranted to be free from defects in material and/or

workmanship for a period of one (1) year from date of original

installation, not to exceed 18 months from date of shipment from

our factory. Any part or component which proves to be faulty in

material and/or workmanship within the warranty period will be

replaced or repaired (at the option of Prince Castle LLC) without

cost to the customer for parts or labor.

This warranty is subject to the following exceptions/conditions:

Use of any non-genuine Prince Castle parts voids th

is

warra

nty and all work must be performed by an aut

horized

Pr

ince Castle Serv

ice Agent.



All labor shall be performed during regular work hours.

Overtime premium will not be cover

ed.



Travel charges are limited to 100 miles (200 kilometers) ro

und

trip, 2 hours travel time, one trip p

er repair.

Damage caused by carelessness, neglect, and/or abuse (e.g.,

using wrong current, dropping, tampering with or altering

electrical components, or improper cleaning) is not covered.

Equipment damaged in shipment, by fire, flood or an act of

God is not covered.

Damage to non-stick coated surfaces is not covered by

this warranty.

355 East Kehoe Blvd. • Carol Stream, IL 60188 USA

Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE

Fax: 630-462-1460 • www.princecastle.com

TABLE OF CONTENTS

Equipment Registration .............................................................. 2

Safety Information ...................................................................... 3

Safety Features .......................................................................... 3

Electrical Specifications .............................................................

3

Installation .................................................................................. 3

Operation ................................................................................... 5

Setting Adjustments ...................................................................

6

Manager Advanced Programming ............................................. 8

Cool Down ................................................................................ 10

Daily Planned Maintenance .....................................................

10

Troubleshooting ....................................................................... 12

Installing the Silicone Belt ........................................................ 13

Removing the Silicone Belt

...................................................... 14

Accessories .............................................................................. 15

Service Kits .............................................................................. 16

Monthly Planned Maintenance ................................................. 19

Exploded Views ........................................................................ 21

Wiring Diagram ........................................................................ 25

Original Instructions

Operation Manual

CTD & CTDE

Vertical Contact Toasters

The CTD Series Vertical Contact

Toaster

This appliance is designed for toasting

bread products in a commercial kitchen.

Customer-adjustable features include:

Bun Compression

Adjustment



Set Point Temperature

Time (Speed of

Conveyor)

The Conveyor B

elt options may be wire,

metal (Stainless Steel) or silicone.

CAUTION: Read Instructions before installing

and using appliance
