PowerWalker VFI 1000 TGS Handleiding

PowerWalker UPS VFI 1000 TGS

Bekijk gratis de handleiding van PowerWalker VFI 1000 TGS (126 pagina’s), behorend tot de categorie UPS. Deze gids werd als nuttig beoordeeld door 9 mensen en kreeg gemiddeld 4.5 sterren uit 5 reviews. Heb je een vraag over PowerWalker VFI 1000 TGS of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/126

USER MANUAL

PowerWalker

VFI 1000-2000-3000 TG

VFI 1000-2000-3000 TGS

EN, DE, PL

CONTENT

1. Safety and EMC Instructions .................................................................... 1

1.1 Installation .............................................................................................. 1

1.2 Operation ............................................................................................... 2

1.3 Maintenance, servicing and faults ......................................................... 3

1.4 Transport ................................................................................................ 4

1.5 Storage ................................................................................................... 4

1.6 Standards ............................................................................................... 4

2. Description of Commonly Used Symbols ............................................... 6

3. Introduction ................................................................................................ 7

4. Panel Description ...................................................................................... 9

4.1 Button ..................................................................................................... 9

4.2 LCD description ................................................................................... 10

5. Connection and Operation ...................................................................... 13

5.1 Inspection: ............................................................................................ 13

5.2 Connection: .......................................................................................... 13

5.3 Battery charge: ..................................................................................... 16

5.4 Turn on the UPS: ................................................................................. 16

5.5 Test function: ........................................................................................ 16

5.6 Turn off the UPS: ................................................................................. 17

5.7 Audible alarm mute function:................................................................ 17

6. Operating Mode for All Models ............................................................... 18

6.1 Line mode ............................................................................................ 19

6.2 Battery mode ........................................................................................ 20

6.3 Bypass mode ....................................................................................... 21

6.4 No Output mode ................................................................................... 21

6.5 EPO (Emergency Power Off) ............................................................... 22

6.6 ECO mode (Economy mode) ............................................................... 22

6.7 CVCF mode ......................................................................................... 22

6.8 Abnormal mode .................................................................................... 23

Product specificaties

Merk:	PowerWalker
Categorie:	UPS
Model:	VFI 1000 TGS
Kleur van het product:	Zwart
Gewicht:	3800 g
Breedte:	102 mm
Diepte:	346 mm
Hoogte:	229 mm
Geluidsniveau:	45 dB
Gewicht verpakking:	4500 g
Breedte verpakking:	194 mm
Diepte verpakking:	423 mm
Hoogte verpakking:	330 mm
Gebruikershandleiding:	Ja
Internationale veiligheidscode (IP):	IP20
LED-indicatoren:	Ja
Vormfactor:	Tower
USB-poort:	Ja
Meegeleverde kabels:	Input power cable, USB cable
Ingebouwde ventilator:	Ja
Accu/Batterij voltage:	12 V
Soort serieële aansluiting:	RS-232
Ondersteund aantal accu's/batterijen:	2
RS-232 port:	1
Uitgangsvermogen:	900 W
ECO mode:	Ja
Frequentie:	40/70 Hz
Stekker:	C14 stekker
Efficientie:	89 procent
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
Type beeldscherm:	LCD
Aantal AC uitgangen:	3 AC-uitgang(en)
Stopcontacttypes:	C13 coupler, C14 coupler
Output power capacity:	1 kVA
Ingang operation voltage (min):	176 V
Ingang operation voltage (max):	300 V
Uitgang operation voltage (min):	220 V
Uitgang operation voltage (max):	240 V
Crest factor:	3:1
UPS-topologie:	Dubbele conversie (online)
Aantal input fases:	1
Seriële interface:	Ja
Emergency Power Off (EPO):	Ja
Uitgangsspanningsregeling:	2 procent
Aantal output fases:	1
Golfvorm:	Zuivere sinus
Input stroom THD:	5 procent
Noodstop-aansluiting (EPO):	Ja
Output vermogensfactor:	0.9
USB-poorttype:	USB Type-B
