1352 Charwood Road • D • Suite Hanover, MD 21076 (410) 761-4000Fax (410) 761-6274 www.polyplanar.com • Tel• •
5.20 ”
Overall Diameter
4.02 ”
Cutout Diameter
1/8”
Hole Diameter
MA4054 Round Speaker Installation Guide
Cutout and use as template for drilling
Installation: Find a suitable location making
sure there is clearance for the installed depth.
Use a hole saw or other suitable device to
make a cutout.
Place the speaker in the cutout and mark
and drill holes for the mounting screws
(supplied). If the panel is too thin or soft for
screws use the stainless screw clips in the
hardware kit.
Attach speaker wires supplied, solid color
wire to positive (white dot or with + sign or
larger tab as shown on the diagram) .
Scale= 1:1
Reproduction may change
accuracy
Mounting Depth
2.13 ”
