XGS-6350-24X4C

XGS-6350-48X2Q4C

PLANET Layer 3 24-/48-Port 10G

SFP+ plus 4-Port 100G QSFP28

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective

owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all environments and applications,

and makes no warranty and representation, either implied or expressed, with respect to the quality,

performance, merchantability, or fitness for a particular purpose. PLANET has made every effort to ensure that

this User's Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have

occurred.

Information in this User's Manual is subject to change without notice and does not represent a commitment on

the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this

User's Manual. PLANET makes no commitment to update or keep current the information in this User's Manual,

and reserves the right to make improvements to this User's Manual and/or to the products described in this

User's Manual, at any time without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your

comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with the Instruction manual,

may cause harmful interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the interference at whose

own expense.

CE Mark Warning

This device is compliant with Class A of CISPR 32. In a residential environment this equipment may cause

radio interference.

WEEE Warning

To avoid the potential effects on the environment and human health as a result of the presence

of hazardous substances in electrical and electronic equipment, end users of electrical and

electronic equipment should understand the meaning of the crossed-out wheeled bin symbol.

Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE

separately.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable to disconnect the device from the power circuit.

Without removing power cable, the device will still consuming power from the power source. In the view of

Saving the Energy and reduce the unnecessary power consuming, it is strongly suggested to remove the

power connection for the device if this device is not intended to be active.

Revision

User’s Manual of PLANET Layer 3 24-/48-Port 10G SFP+ plus 4-Port 100G QSFP28 Managed Switch

Models: XGS-6350-24X4C, XGS-6350-48X2Q4C

Revision: 1.0

Part No: EM-XGS-6350 Series Configuration Guide_v1.0

Product specificaties

Merk:	Planet
Categorie:	Niet gecategoriseerd
Model:	XGS-6350-48X2Q4C
Kleur van het product:	Zwart
Gewicht:	8800 g
Breedte:	442 mm
Diepte:	404 mm
Hoogte:	44 mm
LED-indicatoren:	Ja
Vormfactor:	1U
Aantal USB 2.0-poorten:	1
Vermogensverbruik (max):	147 W
DC voltage input:	36 - 72 V
Certificering:	FCC Part 15 Class A, CE
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3z
Temperatuur bij opslag:	-40 - 80 °C
Aantal ventilatoren:	4 ventilator(en)
Web-gebaseerd management:	Ja
Luchtvochtigheid bij opslag:	5 - 95 procent
Rack-montage:	Ja
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Power over Ethernet (PoE):	Nee
Stapelbaar:	Ja
MAC-adrestabel:	64000 entries
10G support:	Ja
Datastroombeheer:	Ja
Switch type:	Managed
Switch-laag:	L3
Throughput:	1440 Mpps
Jumbo Frames ondersteuning:	Ja
Spanning tree protocol:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
Warmtedissipatie:	504.3 BTU/h
Auto-negotiation:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	0 - 50 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 85 procent
Aantal moduleslots SPF+:	48
Jumbo frames:	9000
Store-and-forward:	Ja
System event log:	Ja
MAC-adres zelflerende functie:	Ja
Traffic-classificatie:	Ja
Half-duplex:	Ja
Aantal GSFP+-moduleslots:	2
Traffic shaping:	Ja
Aantal QSFP28-poorten:	4
