Pagina 1/10

EC10B User’s Manual - page 8

CONTENTS

EC10B User’s Manual - Contents

USER’S MANUAL

EC10B User’s Manual - page 2

Installation

System #1: 2channel input/2-way system withlow level inputs

EC10B User’s Manual - page 1

EC10B User’s Manual - page 6

Input, output, remote and power connections

EC10B User’s Manual - page 3

Front and rear channel controls

EC10B User’s Manual - page 4

EC10B User’s Manual - page 5

Electrical andremote level controller connections

Input and output connections

System #2: 2channel input/2-way system withhigh level inputs

EC10B User’s Manual - page 7

Specifications

EC10B User’s Manual - page 9

This crossover accepts the input signal

from a 2-channel input source, using

either low level RCA outputsor high

level (speaker) outputs from yourhead

unit.

Input source selection

The EC10B features bothlow level (RCA)

inputsand highlevel(speakerlevel)inputs,

enablingyou to generate a two-waysys-

tem from virtually any head unit you may

own.

If yourhead unit has RCA Left and Right

Channel outputs,youshouldchoosethese

foryourEC10B input source, since the

qualityofsound reproductionisbestwhen

using these.

However, if your head unit lacks RCA

outputs, you can use the speaker outputs

from the head unitas an input source for

the EC10B. Simply follow the wiringdia-

grams in this manual closely to make sure

you getthe best performance possible

and avoid damaging your head unit.

Input and output connections vary dependingon the system application. Examples

are shown in system diagramson the pages whichfollow in thismanual. Alwaysuse

high quality RCA cables for low level input and output connections.

EC10B output:2-way stereo system:Tweeter/Mids L/R channel

Subwoofer L/R* channels

* can also be set to Mono Sub channel

To L/R output

fromhead unit

MONOBLOCK

SUBWOOFER AMPLIFIER

FOR

RIGHT CHANNEL

MONOBLOCK

SUBWOOFER AMPLIFIER

FOR LEFT CHANNEL

The EC10B has internal ON/OFF

circuitrywhich responds toturningON

orOFFtheheadunit of yourcar audio

system. This requires that your head

unit have a remote turn-on lead

availableon therearpanel(which most

head units have).

Withthisconvenient remoteturn-on/off

feature, you neverhavetoworryabout

turning off the power to the equalizer

when youshut off the audio system.

Whenyouareconfidentall connections

have been made correctly:

1. Power up your audio system by

turning on the head unit.

2. Set the volume control on the head

unit to about 3/4 volume, and adjust

the EC10B’s SpeakerInput Gain

controlsforeachchannel to justbelow

the level of distortion.

Furtherfine tuningof the controls on

the EC10Band the input levelsof the

connected amplifiers maybe

necessarytoobtainsatisfactoryresults.

If you are unsure abouthow to fine-

tune the system, please consult with

your Planet Audio dealer.

MIDS/HIGHS

2 CHANNEL AMPLIFIER

EC10B output:2-way stereo system:Tweeter/Mids L/R channel

Subwoofer L/R* channels

* can also be set to Mono Sub channel

To L/R speaker outputs

fromhead unit

MONOBLOCK

SUBWOOFER AMPLIFIER

FOR

RIGHT CHANNEL

MONOBLOCK

SUBWOOFER AMPLIFIER

FOR LEFT CHANNEL

MIDS/HIGHS

2 CHANNEL AMPLIFIER

Grey/Black

R(+)

Grey R(-)

White/Black

L(+)

White L(-)

1How this crossover is used

1Input source selection

2Installation

2Mounting the equalizer

2Turning on the power

3Input, output, remote and

power connections

4Front and rear channel

controls

5Electrical and remote level

controller connections

6System diagrams

8Troubleshooting

9Specifications

Congratulations on your

purchase of a Planet Audio

Crossover.

Ithas been designed, engineered

and manufactured to bring you

the highest level of performance

and quality, and will afford you

years of listening pleasure.

Thank you for making

Planet Audio your choice for car

audio entertainment!

EC10B

2-Way Electronic Crossover

with Remote Subwoofer Level Control

page

LOW PASS: 35-400Hz

HIGH PASS: 50-1.5kHz

12dB/octave

0-+12dB

110dB

0.01%

80dB

20k Ohms (low level); 470 ohms (highlevel)

100 Ohms

1:2 (+6dB)

DC-to-DC switching type

8V maximum

4-1/4” x 7-1/14” x 1-1/8”

(108 x 184 x 29mm)

Crossover center frequency ranges

Crossover slope

Bass Boost leveladjustment

Signal-to-Noise Ratio

THD

Channelseparation

Input impedance

Output impedance

Output gain

Power supply

Output voltage

Dimensions (W x D x H)

All specifications subject to change without notice.

Low Pass (Subwoofer) Crossover

Channel Controls:

High Pass (Highs/Mids) Crossover

Channel Controls:

Input Controls:

TWEETERS,

MIDRANGE,

MIDBASS

FULLRANGE

SPEAKERS

SUBWOOFER

Right

Left

SUBWOOFER

Right

Left

TWEETERS,

MIDRANGE,

MIDBASS

FULLRANGE

SPEAKERS
