Pagina 1/26
User manual
UM EN PxCeAPI
Monitoring VL3 IPCs using PxCeAPI
2024-09-25
Phoenix Contact GmbH & Co. KG • Flachsmarktstraße 8 • 32825 Blomberg • Germany
phoenixcontact.com
4173_en_B
Monitoring VL3 IPCs using PxCeAPI
This user manual is valid for:
Designation Version
PxCeAPI (Windows operating system) 1.3.0.7
PxCeAPI (Linux operating system) 1.0.3.1
User manual
UM EN PxCeAPI, Revision B
Table of contents
4173_en_B Phoenix Contact 3/26
Table of contents
1 For your safety............................................................................................................................5
1.1 Labeling of warning notes...................................................................................... 5
1.2 Qualification of users ............................................................................................. 5
1.3 Field of application of the product.......................................................................... 5
1.3.1 Product changes .................................................................................... 5
2 Overview.....................................................................................................................................7
2.1 Supported products............................................................................................... 7
2.2 Programming environment .................................................................................... 8
2.2.1 API file package contents ....................................................................... 8
2.2.2 Installation .............................................................................................. 8
2.3 Sample code ......................................................................................................... 9
2.4 Demo applications................................................................................................. 9
2.5 Other API accessible hardware features ............................................................... 9
3 Programming details.................................................................................................................11
3.1 Type definitions ................................................................................................... 11
3.2 Constants ............................................................................................................ 11
3.2.1 Status codes – (EApiStatus_t) ............................................................. 11
3.2.2 ID Codes - (EApiStatus_t) .................................................................... 12
3.3 Common functions .............................................................................................. 13
3.3.1 EApiLibInitialize ................................................................................... 13
3.3.2 EApiBoardGetStringA .......................................................................... 14
3.3.3 EApiHWMGetCaps .............................................................................. 14
3.3.4 EApiBoardGetValue ............................................................................. 15
3.4 Watchdog timer (WDT)........................................................................................ 15
3.4.1 EApiWDogStart .................................................................................... 16
3.4.2 EApiWDogTrigger ................................................................................ 16
3.4.3 EApiWDogStop .................................................................................... 17
3.5 General purpose I/O ............................................................................................ 17
3.5.1 Constants ............................................................................................. 17
3.5.2 EApiGPIOGetLevel .............................................................................. 18
3.5.3 EApiGPIOSetLevel .............................................................................. 19
3.6 VL3 BPC DIO only functions................................................................................ 19
3.6.1 EApiBoardGetValueWithIndex ............................................................. 19
3.6.2 EApiBoardSetValueWithIndex ............................................................. 20
3.7 Proximity sensor .................................................................................................. 20
3.7.1 EApiGetProximitySensor ..................................................................... 20
3.7.2 EApiSetProximitySensor ...................................................................... 21
