Pagina 1/51
User’s Guide
PCE-PA 8500
PCE-PA 8500 HP
Power Quality Analyzer
03/2022
PCE-PA 8500 (HP) Power Quality Analyzer User‟s Guide
-1-
Introduction
With dual DSP processor architecture, large-scale integrated circuits (FPGA), and
embedded system (uClinux), the PCE-PA 8500 (HP) Power Quality Analyzer can calculate a
large number of electrical parameters and process all data quickly. The Analyzer is
designed specially for power inspection and maintenance department, offering extensive and
powerful measurements to check power distribution system, detecting quality and electrical
characteristics of power grid rapidly and conveniently. The analyzer has large-screen color
LCD display interface, and easy-to-use keyboard.
Main features:
Waveform real-time display(4 voltages/4 currents)
Half cycle RMS measurement (voltage and current)
intuitive operation
variety of optional current clamps
Measure DC component
Measurement, calculation and display of harmonics and interharmonics can be
up to 50 times.
Transient capture
Vector, Trend, Bar Graph and events table display
Active power, reactive power, apparent power and energy, shift power factor and
true power factor
Three-phase unbalance (voltage and current)
Flicker
Inrush current
Detection and record of Dips& Swells, Voltage Rapid Change, Interruption.
Detect according to EN50160 or grid with user-defined limit.
data storage and screenshots (can be replayed or output to a PC)
Through the LAN interface PC can keep real-time remote communication
with the Analyzer, operate the Analyzer and read back measurement data.
Built-in 8G memory card.
