PCE Americas Inc.

711 Commerce Way

Suite 8

Jupiter

FL-33458

USA

From outside US: +1

Tel: (561) 320-9162

Fax: (561) 320-9176

info@pce-americas.com

PCE Instruments UK Ltd.

Units 12/13

Southpoint Business Park

Ensign way

Hampshire / Southampton

United Kingdom, SO31 4RF

From outside UK: +44

Tel: (0) 2380 98703 0

Fax: (0) 2380 98703 9

info@pce-instruments.com

Test stand LTS-20

Manual test stand for force gauges. The crank-operated test stand LTS-20 can be used in combination

with dierent PCE force gaugesWith the test stand LTS-20, you can perform tensile and compressive .

force measurements up to 1000 N respectively 100 kg. By using a test stand, you can always be sure to

get consistent and repeatable results. The test stand LTS-20 is operated manually by using the crank

handle on top.

Specications

Max. travelling distance: 345 mm

Total length: 530 mm (without crank handle)

Crank handle diameter: 120 mm

Leadscrew diameter: 15 mm

Leadscrew thread pitch: 2 mm

Base dimensions: 250 x 230 mm

Base plate: 145 x 100 mm

Weight: 7 kg

Max. force: 1.000 N

Please notice:

Depending on your force gauge, a special mounting plate may be

necessary to attach the gauge to the test stand. Please contact our

customer support for more information.

Optional accessories:

Wedge grip: Self-fastening wedge grip with lever for fast opening of

the clamp. Ideal for material thicknesses up to 5 mm.

Wedge grip and force gauge not

included in the package
