Pagina 1/35
CA9 APPLICATOR
PA23998A01
Rev. 09 12-2023
FOR USE IN AUTOMATIC WIRE PROCESSING MACHINES
AND BENCH PRESSES
OPERATION MANUAL
© Panduit Corp. 2011
FEEDS AND CRIMPS Reel Smart™ CONTINUOUSLY MOLDED
TERMINALS, DISCONNECTS AND SPLICES IN AUTOMATIC
WIRE PROCESSING MACHINES AND BENCH PRESSES
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Website: www.panduit.com
Email: cs@panduit.com
EU Website:
www.panduit.com/emea
EU Email
:
emeatoolservicecenter
@panduit.com
Panduit Corp. • USA Technical Support
Tel: 888-506-5400, ext. 3255 • Fax: 630-759-7532
Panduit Europe • EMEA Service Center
Almelo, Netherlands
Tel: +31 546 580 452 • Fax: +31 546 580 441
CA9 APPLICATOR
TABLE OF CONTENTS
INTRODUCTION ..................................................................................................... 1
SYSTEM SPECIFICATIONS ................................................................................... 1
SAFETY PRACTICES ............................................................................................. 1
WIRE PROCESSING MACHINE / PRESS COMPATIBILITY BY MANUFACTURER 4
APPLICATOR INSTALLATION .............................................................................. 5
AMP CLS III G, CLS IV, & CLS IV PLUS WIRE PROCESSING MACHINES & G BENCH PRESS5
AMP CLS II & CLS III WIRE PROCESSING MACHINES AND T BENCH PRESS ....................... 6
ARTOS CS-600 WIRE PROCESSING MACHINE WITH AMP G PRESS .................................... 7
ARTOS CS-600 WIRE PROCESSING MACHINE WITH TU-10 PRESS ...................................... 9
ARTOS MTX Series 5 WIRE PROCESSING MACHINE WITH TU-10 PRESS ........................... 10
GAMMA MECCANICA T20P-110V BENCH PRESS................................................................... 11
KODERA SERIES C451/C450 & C551/C550 WIRE PROCESSING MACHINES ....................... 12
KOMAX GAMMA 311 WIRE PROCESSING MACHINE WITH MECAL K300 PRESS ............... 13
KOMAX GAMMA 333 OR ALPHA 433 WIRE PROCESSING MACHINE WITH MCI 711 PRESS14
KOMAX ALPHA 411 WIRE PROCESSING MACHINE WITH MECAL PE7 OR P107 PRESS ... 15
KOMAX 40T WIRE PROCESSING MACHINE WITH MECAL PE7 PRESS ............................... 17
MEGOMAT ASM 3001A & PRIMO WIRE PROCESSING MACHINES ....................................... 18
Panduit CP-862 BENCH PRESS ................................................................................................ 19
Panduit CP-871 BENCH PRESS ................................................................................................ 20
SCHLEUNIGER CRIMPCENTER 12 WIRE PROCESSING MACHINE WITH ACP 01 PRESS . 21
SCHLEUNIGER UniCrimp 208 ................................................................................................... 23
SHINMAYWA TRD111 OR TR111 WIRE PROCESSING MACHINE ......................................... 24
APPLICATOR SETUP .......................................................................................... 25
DIE INSERT INSTALLATION ................................................................ 25
DIE INSERT CHANGEOVER ................................................................ 27
Reel Smart™ SYSTEM REFERENCE TABLE ..................................................... 28
CRIMP SHUT HEIGHT TOLERANCE TEST ........................................ 29
APPLICATOR LOADING ...................................................................... 29
OPERATION ......................................................................................................... 31
SAFETY CHECKLIST ........................................................................... 31
OPERATION PROCEDURE ................................................................. 31
MAINTENANCE .................................................................................... 31
TROUBLESHOOTING .......................................................................................... 31
DETERMINING CORRECT AND INCORRECT TERMINATIONS ........ 31
TROUBLESHOOTING CHECKLIST ..................................................... 32
