Zoom lens

Operating Instructions

Thank you for purchasing this Panasonic product.

■

To ensure correct use of this lens, please read the operating instructions supplied

with the lens and the projector carefully.

■

Before using this product, be sure to read “Read this rst!” (



Page 3).

■

Please save this manual for future use.

2-ENGLISH

Read this rst! ......................................................................................3

Before Use.............................................................................................4

Preparation............................................................................................6

Before replacing the projection lens ........................................................ 6

Attaching the Lens................................................................................... 6

Using the Lens Fixed Attachment for Portrait Installation........................ 9

Moving the Lens to the Home Position.................................................. 11

Lens Shift Adjustment............................................................................ 13

Detaching the Lens ............................................................................... 15

Focus Adjustment .................................................................................. 16

Projection relationships.....................................................................19

Lens shift ranges ................................................................................21

Specications .....................................................................................23

Dimensions .........................................................................................23

Projected image size and Projection distance.......Appendix / Annexe /

付録

The "Appendix" can be found after the Japanese language section (

日本語

█ Contents

Product specificaties

Merk:	Panasonic
Categorie:	Niet gecategoriseerd
Model:	ET-DLE020
Kleur van het product:	Zwart
Gewicht:	3200 g
Brandpuntbereik:	4.1 - 4.4 mm
Throw ratio:	0.280 - 0.309:1
Merkcompatibiliteit:	Panasonic
Compatibiliteit:	PT-RCQ10, PT-RCQ80, PT-RZ120, PT-RZ970, PT-RW930, PT-RX110, PT-RZ870, PT-RZ770, PT-RW730, PT-RZ660, PT-RW620
Afmetingen (B x D x H):	170 x 391 x 170 mm
Type product:	Lens
Code geharmoniseerd systeem (HS):	90021100
Projectieformaat:	100 - 400
