Pagina 1/11
Multi-Camera
Sync Hub Dev/Pro
Datasheet v1.0
Product Brief
Product Information
Multi-Camera Sync Hub Internal
Connections
Multi-Camera Sync Interface and
Electrical Parameters
Cables
Multi-Camera Setup Extended Connection
Additional Interfaces of Multi-Camera
Sync Hub Dev
Software Conguration
02
03
04
05
06
07
08
08
Copyright 2023 Orbbec Inc. All rights reserved. The product described may contain defects or errors or deviation from published specications.
Contact your sales representative to obtain the latest Orbbec 3D product specications. Orbbec is not responsible for any users infringing on third party
copyright or other rights while using Orbbec products. In addition, Orbbec does not assume any liability for damages or any losses resulting from the use
of this product. All information provided here is subject to change without notice.
Product Overview
Multiple cameras are used to
increase camera coverage, ll in
occlusions where a single camera
might have blind spots or blockage,
capture multiple images of the same
scene from different viewpoints
or angles or increase the effective
frame rate. Orbbec’s Sync Hubs are
available in two versions, the Sync
Hub Dev and Sync Hub Pro, and are
designed to reduce the complexity
and cost of a multi-camera network
of compatible Orbbec cameras and
external sensors. The trigger voltage
is switchable, and the number of
secondary devices can be extended
using multiple hubs.
The Developer edition, compact
and exible, uses a GPIO interface,
perfectly meeting rapid prototyping
needs during early-stage
development. The Professional
edition, designed for commercial use,
employs a reliable RJ45 interface,
guaranteeing a more stable and
longer-range signal connection using
standard CAT5 or better cables.
1. Product Brief
Product Features
• Compact, dedicated versions for
Star or Daisy Chain connections
• 1 Primary and up to 4 Secondary
devices, extensible by connecting
additional hubs
• Uses 8-pin at cables
• Switchable voltages when used
with USB-C power supply or 5V
input
ORBBEC. All Rights Reserved. https://orbbec3d.com/
Note: Orbbec reserves the right to change any information in the document without prior notice.
Contact us: info@orbbec3d.com | 2800 Livernois Rd, Troy, MI 48083 USA
02
Multi-Camera Sync Hub Dev/Pro | Datasheet v1.0
Sync Hub Dev, Star and Daisy Chain:
• Compact, mountable enclosure
• Ingenuous use of industry standard
RJ45 interfaces and CAT5 or better
cables
• Supports 1 Primary and up to 8
secondary devices in Star format,
extensible by connecting additional
hubs
• Switchable voltages when used
with USB-C power supply
Sync Hub Pro:
