User manual

DLP

Projector

English

TABLE OF CONTENTS

SAFETY ............................................................................................... 4

Important Safety Instruction....................................................................................................... 4

3D Safety Information ................................................................................................................ 5

Copyright ................................................................................................................................... 6

Disclaimer .................................................................................................................................. 6

Trademark Recognition ............................................................................................................. 6

FCC ........................................................................................................................................... 7

Declaration of Conformity for EU countries ............................................................................... 7

WEEE ........................................................................................................................................ 7

INTRODUCTION ................................................................................ 8

Package Overview..................................................................................................................... 8

Standard accessories ................................................................................................................ 8

Optional accessories ................................................................................................................. 8

Product Overview ...................................................................................................................... 9

Connections.............................................................................................................................. 10

Keypad ..................................................................................................................................... 12

Remote control 1 ...................................................................................................................... 13

Remote control 2 ...................................................................................................................... 14

Remote control 3 ...................................................................................................................... 15

Remote control 4 ...................................................................................................................... 16

SETUP AND INSTALLATION ........................................................... 17

Installing the projector .............................................................................................................. 17

Adjusting the projector image ................................................................................................... 23

USING THE PROJECTOR ............................................................... 26

Powering on / o the projector .................................................................................................. 26

Selecting an input source ......................................................................................................... 27

Menu navigation and features .................................................................................................. 28

OSD Menu tree (SVGA, XGA, and WXGA models) ................................................................. 29

Display image settings menu.................................................................................................... 37

Display 3D menu ...................................................................................................................... 39

Display aspect ratio menu ........................................................................................................ 40

Display edge mask menu ......................................................................................................... 42

Display zoom menu .................................................................................................................. 42

Display image shift menu ......................................................................................................... 42

Display keystone menu ............................................................................................................ 42

Audio mute menu ..................................................................................................................... 43

Audio volume menu .................................................................................................................. 43

Setup projection menu.............................................................................................................. 44

Setup screen type menu........................................................................................................... 44

Setup lamp settings menu ........................................................................................................ 44

Product specificaties

Merk:	Optoma
Categorie:	Beamer
Model:	H190X
Kleur van het product:	Zwart
Gewicht:	3050 g
Breedte:	316 mm
Diepte:	244 mm
Hoogte:	108 mm
Geluidsniveau:	27 dB
Gebruikershandleiding:	Ja
Stroombron:	AC
Oorspronkelijke beeldverhouding:	16:10
Ondersteunde video-modi:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Meegeleverde kabels:	AC
Typische contrastverhouding:	30000:1
Zoomcapaciteit:	Ja
Markt positionering:	Draagbaar
Projector helderheid:	3900 ANSI lumens
Projectietechnologie:	DLP
Projector native resolution:	WXGA (1280x800)
Keystone correctie, verticaal:	-40 - 40 °
Geschikt voor schermmaten:	32.24 - 299.53 "
Projectie-afstand objectief:	1 - 12 m
Frequentiebereik horizontaal:	15.38 - 91.15 kHz
Frequentiebereik verticaal:	50 - 85 Hz
Aantal USB 2.0-poorten:	1
VGA (D-Sub)poort(en):	1
Aantal HDMI-poorten:	1
Soort serieële aansluiting:	RS-232
Audio-ingang (L, R):	1
Composiet video-ingang:	1
Componentingang video (YPbPr/YCbCr):	1
Zoom type:	Handmatig
Brandpuntbereik:	21.85 - 24 mm
Levensduur van de lichtbron:	6000 uur
Type lichtbron:	Lamp
Bevestigingsmogelijkheid voor kabelslot:	Ja
Kabelslot sleuf type:	Kensington
Ingebouwde luidsprekers:	Ja
Gemiddeld vermogen:	10 W
Aantal ingebouwde luidsprekers:	1
Stroomverbruik (in standby):	0.5 W
Vermogensverbruik (max):	225 W
Ondersteunde beeldverhoudingen:	4:3, 16:10, 16:9
Zoomverhouding:	1.1:1
Throw ratio:	1.55:1 - 1.73:1
Off-set:	112 procent
Formaat analoog signaal:	NTSC M, PAL B, PAL D, PAL G, PAL H, PAL I, PAL M, PAL N, SECAM B, SECAM D, SECAM G, SECAM K, SECAM K1, SECAM L
3D:	Ja
Lampvermogen:	203 W
HDMI versie:	1.4a
On Screen Display (OSD)-talen:	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, IND, ITA, JPN, NOR, POL, POR, RUM, RUS, SWE, TUR, VIE
Audio (L,R) out:	1
On Screen Display (OSD):	Ja
Aantal On Screen Display-talen:	25
Levensduur van de lichtbron (besparingsmodus):	10000 uur
Hoogte, in bedrijf:	0 - 3000 m
Eenvormigheid:	75 procent
Afstandsbediening inbegrepen:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Stroomverbruik (typisch):	187 W
Bedrijfstemperatuur (T-T):	5 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 85 procent
Batterijen inbegrepen:	Ja
Type product:	Projector met normale projectieafstand
Ondersteunde 3D-formaten:	Frame packing, Side by side, Top and bottom
3D verticaal scanbereik:	50 - 120 Hz
