Satco Products, Inc.

Brentwood, NY 11717© Copyright 2023 Satco Products, Inc. 4/23

1

WARNING: Risk of Fire or Electric Shock

• To avoid damage, falling, electric shock or re, do not modify the lamp or

replace accessories without conrming with the supplier rst.

• Only authorized, qualied personnel should install this xture and should

follow the owner’s manual. Any improper installation might cause failure,

electric shock, re or other injury, damage or hazard.

• Disconnect power before installation or any maintenance of the xture.

• Do not dismantle the xture without the supplier’s authorization.

• Do not touch the power supply when the xture is operating.

• The external flexible cable or cord of this xture cannot be replaced; if the

cord is damaged, the xture shall be destroyed.

• Terminal block not included. The electrical tting must be installed by a

licensed electrician.

• For use in environments where an accumulation of non-conductive dust

on the xture may be expected.

IMPORTANT: This product must be installed in accordance with the

applicable installation code by a person familiar with the construction and

operation of the product and the hazards involved. This product is suitable

for 120V only.

LED

HI-PRO SHOP LIGHT

Models:/960,/961,/962,/963,/964,/965, 65 65 65 65 65 65

65/970,5/971,6/972,5/973,5/974,5/975 6 9 6 6 6, 65/956, 95/957, 65/959

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

WIRING DIAGRAM & INSTRUCTIONS

This product is suitable for both plug in and hardwire applications.

For hardwired applications, cut plug and strip back the SVT to

access the leads. Make sure power is off and connect the black

wire to the AC Line, the white to the AC Neutral and the green to

the ground. Make sure all connections are capped and sealed. Turn

power back on.

INSTALLATION: Hook Mount

STEP 1: Screw the hook into the fixture, tighten

and secure.

STEP 2: Hang the fixture on the ceiling hook

or chain.

STEP 3: Connect wires using the wiring diagram and

instructions on gure 1. Make sure connections are

capped and sealed.

120V

Figure1
