Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-TAC-540XL-24

Instruction Manual

TAC-540XL

US PATENT 9,713,217

THANK YOU FOR SELECTING THE NIGHTSTICK TAC!

Please read these instructions before using your TAC. They include important

safety and operation information. WARNINGS

WARNINGS

yNOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product in

explosive atmospheres, near ammable liquids, or where explosion proof or

intrinsically safe lighting is required.

yDO NOT use this product in the proximity of vehicles or equipment when there is

a risk of ammable liquids coming into contact with the ashlight.

yLight can become hot while on. To prevent damage DO NOT cover or place next

to any potentially ammable materials while in use.

yKeep out of the reach of children.

OPERATION

NOTE: The TAC-540XL is rechargeable-ready. By adding the optional Lithium-

ion Rechargeable Battery, the wall or vehicle mountable Charger and the AC and/

or DC Power Supply, the TAC-540XL ashlight can operate as a fully rechargeable

tactical ashlight.

The TAC has four light modes: momentary ashlight, full brightness ashlight,

medium brightness ashlight and low brightness ashlight. The TAC has a single tail

switch providing access to all modes.

MOMENTARY FLASHLIGHT MODE

Lightly press the tail switch for momentary operation. Release the switch to turn

the light off.

CONSTANT-ON

Press the tail switch until it clicks and then release for constant-on in high-

brightness mode. Press and release the tail switch again to turn the light off.

SELECT BRIGHTNESS LEVEL

Press and hold down the tail switch. The light will cycle from high to medium to

low and then back up again at a rate of approximately one mode per second. The

light will continue to cycle up and down through the various modes as long as the tail

switch is held down. When the desired brightness level is reached, simply release

the tail switch, and the light will remain in that brightness mode. Pressing and holding

the tail switch again will cause the light to cycle from whatever mode it is currently in.

Press and release the tail switch to turn the light off.

CR-123 BATTERY CARRIER

The CR123 battery carrier converts the TAC from rechargeable Lithium-ion to

non-rechargeable Lithium battery operation.

Load two CR-123 Lithium batteries with the positive terminals pointing in the

direction of the arrow. NOTE: The ashlight cannot be charged with the CR-123

CARRIER installed.

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship

and materials for the original purchaser’s lifetime. The Limited Lifetime Warranty

includes the LEDs, housing and lenses. Rechargeable batteries, chargers, switches,

electronics and included accessories are warranted for a period of two years with

proof of purchase. Normal wear and failures which are caused by accidents, misuse,

abuse, faulty installation and lightning damage are excluded.

We will repair or replace this product should we determine it to be defective. This

is the only warranty, expressed or implied, including any warranty of merchantability

or tness for a particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/bayco-

product-support/warranties. Retain your receipt for proof of purchase.

Mode d’emploi

TAC-540XL

MERCI D’AVOIR CHOISI LA TORCHE ÉLECTRIQUE NIGHTSTICK TAC!

Veuillez lire ces instructions avant d’utiliser votre TAC. Elles comprennent des

informations importantes liées à la sécurité et à l’utilisation de ce produit.

AVERTISSEMENTS

yNE PAS UTILISER DANS DES ENDROITS DANGEREUX. Ne pas utiliser ce

produit dans des atmosphères explosibles, à proximité de liquides inammables,

ou un endroit antidéagrant ou un emplacement dont un éclairage à sécurité

intrinsèque est requis.

yNE PAS utiliser ce produit à proximité de véhicules ou équipements quand il y a

risque de liquides inammables entrant en contact avec la lampe de poche.

yLa lumière peut être chaude lorsqu’elle est allumée. Pour éviter tout dommage

NE PAS couvrir ou placer à proximité de matériaux potentiellement inammables

pendant qu’elle est allumée.

yGarder hors de la portée des enfants.

FONCTIONNEMENT

REMARQUE : La lampe torche TAC-540XL est prête à être rechargée. Si vous

ajoutez la batterie rechargeable optionnelle au lithium-ion, le chargeur montable

pour mur ou véhicule et l’alimentation c.a. et/ou c.c., la lampe torche TAC-540XL

peut être utilisée comme lampe torche tactique rechargeable.

Le TAC contient quatre modes de lumières : lampe de poche à lumière

momentanée, lampe de poche à luminosité maximale, lampe de poche à luminosité

Included in the box - Compris dans la boîte - Incluido en la caja
