Instruction Manual

XPR-5584

US PATENT 9,713,217, 10,879,529, 11,450,934

THE XPR-5584 IS APPROVED FOR USE

Bayco Products, Inc. XPR-5584GMX

640 S. Sanden Blvd., Wylie, TX 75098

MFG MM-YY

SEE INSTRUCTION MANUAL

VOIR MANUEL

Ex ia FLASHLIGHT FOR USE IN HAZARDOUS LOCATIONS

UL listed for use with Bayco Li-ion Battery Pack 5584-BATT

E 467756

INTRINSICALLY SAFE

SECURITE INTRINSEQUE

ID 4003544

2903

CLASS I DIV 1 GRPS A-D T4

CLASS II & III DIV 1 GRPS E-G T135ºC

CLASS I ZONE 0 AEx ia op is IIC T4 Ga

Ex ia op is IIC T4 Ga

DEMKO 19 ATEX 2254

UL22UKEX2428

IECEx UL 19.0075

-20ºC ≤ Tamb ≤ +40ºC

3.6V/Cell 5584-BATT

Um 10V

II 1 G Ex ia op is IIC T4 Ga

WARNING: Do not charge battery in a hazardous location

WARNING: Do not replace battery when an explosive

atmosphere is present

ATENÇÃO – VER MANUAL DE INSTRUÇÕES

22-AV4BO-0220X

Ex ia op is IIC T4 Ga

(-20ºC ≤ Tamb ≤ +40ºC)

NCC 21.0076

WARNINGS - INTRINSICALLY SAFE

yWarning: To prevent ignition of a hazardous atmosphere, do not locate the charger for this product

in the hazardous environment. The charger for this product must be located in an area known to

be non-hazardous ONLY.

yWarning: To prevent ignition of a hazardous atmosphere, do not attempt to charge this product in the

hazardous environment. This task must ONLY be performed in an area known to be non-hazardous.

yWarning: Lithium-ion batteries must be used and charged properly. Improper use can result in

serious injury, re, or death.

yWarning: Use only the included and approved 5584-BATT rechargeable battery pack from Bayco

Products.

yWarning: Do NOT attempt to use any other rechargeable or non-rechargeable batteries with this

light.

yWarning: To prevent ignition of a hazardous atmosphere, do not open or remove the bottom plate

and/or lens bezel in a hazardous environment. This task must ONLY be performed in an area known

to be non-hazardous.

yWarning: When exchanging the rechargeable battery pack, use only the approved 5584-BATT

rechargeable battery pack from Bayco Products.

yWarning: To prevent ignition of a hazardous atmosphere, the rechargeable battery pack must only

be exchanged in an area known to be non-hazardous.

yWarning: Do not expose the rechargeable battery pack to water or salt water, or allow the battery

pack to get wet.

yWarning: Do not store the rechargeable battery pack with metallic objects that may cause a short

circuit.

yWarning: Substitution of components may impair intrinsic safety.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

For personal safety, always conrm the rating of any known hazardous or potentially hazardous

location where the light is to be used.

INITIAL USE

Warning: To prevent ignition of a hazardous atmosphere, do not attempt to charge this

product in the hazardous environment. This task must ONLY be performed in an area known

to be non-hazardous.

Fully charge the XPR-5584 before the rst use, or if the battery is new or has been unused for

several months. The maximum charge time required is approximately 6 hours.

DAILY USE

WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE, DO NOT ATTEMPT TO

CHARGE THIS PRODUCT IN THE HAZARDOUS ENVIRONMENT. THIS TASK MUST ONLY BE

PERFORMED IN AN AREA KNOWN TO BE NON-HAZARDOUS.

yUse only the supplied Nightstick charger, 5584-BATT rechargeable battery pack and AC or DC

adapter. For best performance, charge the 5584 when the ashlight beam starts to dim.

yConnect the AC power adapter to the charger. The LED indicator will not be illuminated at this point.

yWith the ashlight facing forward, slide the 5584 into the charger until the contacts snap into place.

yThe LED indicator changes to constant red indicating the 5584 is properly inserted into the charger

and is charging. The LED indicator remains red until the battery is fully charged. At full charge, the

LED indicator turns green.

yThe total time to fully charge the 5584 varies depending on the remaining charge in the battery

pack.

yTo conrm a full charge, keep the 5584 in the charger and turn it on. The LED indicator will

change to red. Turn off the 5584. If the 5584 is fully charged, the LED indicator will turn green. If

not, it remains red until the charge is completed and the LED indicator turns green. The 5584 will

now be fully charged.

REPLACING LITHIUM-ION RECHARGEABLE BATTERY

The XPR-5584 is designed to allow the end user to replace the battery pack if necessary.

Carefully follow the instructions below:

CHARGER INPUT: 12 VDC MAX.

WARNING: WHEN EXCHANGING THE RECHARGEABLE BATTERY PACK, USE ONLY THE

APPROVED 5584-BATT RECHARGEABLE BATTERY PACK FROM BAYCO PRODUCTS.

WARNING: TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE, THE

RECHARGEABLE BATTERY PACK MUST ONLY BE EXCHANGED IN AN AREA KNOWN TO

BE NON-HAZARDOUS.

yLoosen the screws located on the bottom of the light and remove the plate to expose the

battery pack.

yThe battery is connected to the light with a wire that has a snap connector. Remove the battery

pack from the light by rst disconnecting the wires that snap together.

yUsing only the approved replacement 5584-BATT rechargeable battery pack from Bayco

Products, place the new battery pack into the housing and reconnect the wires.

yReplace the base plate and tighten all the screws. CAUTION: Do NOT overtighten the screws.

Doing so may damage the threads and impact the light’s intrinsic safety.

OPERATION

Turn Light On/Off:

Press and release the ashlight switch. The light will turn on in high brightness mode. Press and

release to turn off.

Select Brightness Level:

Press and hold the ashlight switch. The light will cycle from high to low and back at a rate of

approximately one mode per second and will continue to cycle while the switch is held down. Release

the switch when the desired brightness level is reached.

Rear Light:

The rear green LED light stays on while ashlight is in operation regardless of mode selected.

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship and materials for

the original purchaser’s lifetime. The Limited Lifetime Warranty includes the LEDs, housing and lenses.

Rechargeable batteries, chargers, switches, electronics and included accessories are warranted for a

period of two years with proof of purchase. Normal wear and failures which are caused by accidents,

misuse, abuse, faulty installation and lightning damage are excluded.

We will repair or replace this product should we determine it to be defective. This is the only warranty,

expressed or implied, including any warranty of merchantability or tness for a particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/bayco-product-support/

warranties. Retain your receipt for proof of purchase.
