MSI D3066 Handleiding
Bekijk gratis de handleiding van MSI D3066 (48 pagina’s), behorend tot de categorie Server. Deze gids werd als nuttig beoordeeld door 19 mensen en kreeg gemiddeld 3.7 sterren uit 10 reviews. Heb je een vraag over MSI D3066 of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/48
HPM D3066
MS-S3761
Server Motherboard
User Guide
2
Contents
Revision
V1.0, 2025/05
Contents
Regulatory Notices ...................................................................................................4
System Specifications .............................................................................................7
Rear I/O .....................................................................................................................9
OCP 3.0 NIC Mezzanine Slot .................................................................................. 9
DC-SCM ................................................................................................................... 9
Overview of Components .....................................................................................10
Block Diagram ........................................................................................................13
CPU Socket .............................................................................................................14
CPU Installation ................................................................................................... 15
Assembly Overview ........................................................................................ 15
Memory ...................................................................................................................19
Key Parameters for DIMM Configuration ....................................................... 20
Granite Rapids-SP DDR DIMM Support Matrix ............................................... 20
Support Matrix for Intel Xeon 6500P/6700P-series ........................................ 20
Sierra Forest- SP DDR DIMM Support Matrix .................................................. 20
Support Matrix for Intel Xeon 6700E-series ................................................... 20
DDR5 Only DIMM Configuration ..................................................................... 21
Installing Memory Modules ................................................................................. 22
Connectors .............................................................................................................23
Power Connectors ................................................................................................ 23
PICPWR0~1/3~5: PIC Power Connectors .......................................................... 23
PICPWR0~1: PDB Power Connectors ............................................................. 23
PICPWR3, PICPWR4: GPU Power Connectors ................................................ 23
PICPWR5: Fan Power Connector .................................................................... 23
PICPWR0~1/3~5: PIC Power Connectors ........................................................ 24
*SB: The term“ SB” stands for sideband. ........................................................... 24
PWR1: Rear Side BP Power Connector ........................................................... 24
Storage Connectors ............................................................................................. 25
