D3060
MS-S4171
Server Motherboard
User Guide
2 3
Revision
V1.0, 2025/06
Contents
Regulatory Notices ..........................................................................................................4
Safety Information
........................................................................................................... 7
Specifications ..................................................................................................................9
Overview of Components ............................................................................................11
Rear I/O Panel ................................................................................................................12
Block Diagram ...............................................................................................................14
CPU Socket ....................................................................................................................16
Assembly Overview .................................................................................................... 17
Installing CPU & Heatsink ........................................................................................... 18
Memory Slots .................................................................................................................22
P0_DIM_A0~H0, : DDR5 DIMM Slots ........................................................................... 22
Recommended Memory Population ......................................................................... 23
Installing Memory Modules ........................................................................................ 27
Storage Connectors ......................................................................................................28
M2_0~1: M.2 Slots (M Key, 2280/ 22110) .................................................................... 28
JSLIM0~2: SlimSAS 4i Connectors ............................................................................. 29
Expansions .....................................................................................................................30
PCIE_SLOT1, 3, 5, 7: PCIe Expansion Slots ................................................................ 30
JMCIO0~5: MCIO 8i Connectors ................................................................................. 31
Power Connectors ........................................................................................................32
JPWR0: 24-Pin ATX Power Connector ........................................................................ 32
JPWR1~2: 8-Pin ATX Power Connectors .................................................................... 32
Cooling Connectors ......................................................................................................33
JFAN1~2: 6-Pin Fan Connectors ................................................................................. 33
JCPUFAN0, JFAN0, 3: 4-Pin Fan Connectors .............................................................. 33
