Outdoor unit service manual
MUZ-HM•NA Series (OBH747)
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
PARTS CATALOG (OBB746)
MSZ-HM24NA
INDOOR UNIT
SERVICE MANUAL
INDOOR UNIT
Models
MSZ-HM09NA
-
U1
MSZ-HM12NA
-
U1
MSZ-HM15NA
-
U1
MSZ-HM18NA
-
U1
MSZ-HM24NA
-
U1
CONTENTS
1. TECHNICAL CHANGES
·······································
2
2. PART NAMES AND FUNCTIONS ·····················3
3. SPECIFICATION ················································5
4. OUTLINES AND DIMENSIONS ························7
5. WIRING DIAGRAM ············································8
6. REFRIGERANT SYSTEM DIAGRAM ···············9
7. SERVICE FUNCTIONS ···································10
8. MICROPROCESSOR CONTROL ···················12
9. TROUBLESHOOTING ·····································16
10. DISASSEMBLY INSTRUCTIONS ····················30
No. OBH746
REVISED EDITION-B
Please void OBH746 REVISED EDITION-A.
Revision B:
• 3-1. OPERATING RANGE has been modified.
